Machine frame SIPLACE 80 F5
Page 24 / 31 19.11.2021
Machine frame SIPLACE 80 F5
Page 25 / 31 19.11.2021
Pos. Item no. Description Part marking
00320704-02 MACHINE FRAME SIPLACE 80 F 4
1 00320704-02 MACHINE FRAME SIPLACE 80 F 4
2 00320793-06 FRAME - BASE UNIT
3 00346032-04 CONTAINER, SMALL
4 00318664-06 WELDED PART FRAME SIPLACE 4
5 00351165-02 U-PROFILE WITH MOTOR CUTAWAY
6 00346047-05 U-PROFILE W. SOCKET
7 00346037-01 COVER
8 00350252-01 HOOD
9 00346050-01 PROTECTION
10 00345988-01 PROTECTION
13 00346000-03 U-PROFILE
14 00346031-03 U-PROFILE
15 00321224-02 MACHINE BASE NORMAL HEIGHT
SIPL
SPARE PART
16 00321245-01 SPRING TYPE STRAIGHT PIN
17 00321225-01 MACHINE BASE HOLDER
18 00321226-01 MACHINE BASE REWORK
19 00304184-01 LOCK WITH DOUBLE BIT / BAR
20 00304191-01 DIN 43668 - 3 - C35 STANDARD PARTS
21 00304400-02 COVER ANGLE SPARE
22 00346062-01 COVER
23 00304635-02 SLIDING PLATE
24 00322191-03 SLIDING PLATE
25 00322190-02 SLIDING PLATE
26 00315645-01 DISTANCE BOLT
27 00312474-01 HEXAGON SOCKET HEAD CAP
SCREW
28 00348952-03 PLUG-IN SEQUENCE COMPON.
TABLE S23/F5HM
SPARE PART
32 00320635-01 PORTAL SUPPORT COMPLETE
33 00320671-01 GUIDE RAIL TKD 25N/1660 Spare Part
34 00313994-01 HEXAGON SOCKET HEAD CAP
SCREW
35 00619841-01 PARALLEL PIN 3M5 X 8-ST
36 00318481-03 PORTAL SUPPORT
Machine frame SIPLACE 80 F5
Page 26 / 31 19.11.2021
Pos. Item no. Description Part marking
37 00319220-01 GUIDE PLATE
38 00322461-01 HEXAGON SOCKET HEAD CAP
SCREW
39 00315594-01 CAM ROLLER KR 16 X SPARE PART
40 00349922-02 PC-HOLDER 4
41 00347747-01 CURVED CROSSHEAD PC-SUPP.3
(S23)
42 00337391-01 PLUG-SQUARE GPN270R10050
100*50
SPARE PART
43 00349923-02 MOUNTING PC-SUPPORT 4
44 00349924-01 HOUSING PC-SUPPORT 4
45 00328376-01 GUIDE PC-SUPPORT 2 SPARE PART
46 00845060-01 HEXAGON SOCKET HEAD CAP
SCREW M6 X 25-8.8
47 00095474-01 DISC 6,4 DIN125-A Spare
48 00845024-01 HEXAGON SOCKET HEAD CAP
SCREW M4 X 8-8.8
49 00095472-01 PLAIN WASHER A 4.3-140HV-ST
50 00349929-01 MAIN ERROR DISPLAY PC-SUPPORT
4
51 00321320S01 INCANDESCENT LAMP 24V/5W BASE
BA15D
WEAR PART
52 00349930-01 LAMP HOLDER PC-SUPPORT 4
53 00326152-01 PULL RELIEF TYPEKK2
54 00313846-01 DIN912-M5 X 18-A2-70
55 00321575-02 CABLE: MAIN ERROR DISPLAY
56 00349928-01 CABLE COVER PC-SUPPORT 4
57 00845023-01 HEXAGON SOCKET HEAD CAP
SCREW M4 X 6-8.8
58 03052954-01 MONITOR HOLDER S U. F
COMPLETE
SPARE PART
59 00350470-01 REST SCENIC 620 - PC-SUPPORT 4
60 00845059-01 HEXAGON SOCKET HEAD CAP
SCREW M6 X 20-8.8
61 00095474-01 DISC 6,4 DIN125-A Spare
62 00347748-01 ANGLE LEFT SIDE (PC-SUPP.3, S23)
63 00346042-01 PLATE PC-SUPPORT 3
64 00332287-01 HEXAGON SOCKET HEAD CAP
SCREW
