Machine frame SIPLACE 80 F5
Page 29 / 31 19.11.2021
Pos. Item no. Description Part marking
133 00048335-01 DIN 9021 - 4.3 - 140 HV - ST DISK
134 00319223-03 BE-REJECT BOX (EGB) SPARE PART
136 00300272S07 PLUG IN FOR SERVICE Spare Part
137 00823069-01 SOCKET ST-3/S SNAP-ON
138 00344533-01 MAINS FILTER 3 PHASES COMPLETE
WITH PG
139 00302818-01 AUTOMATIC CIRCUIT BREAKER 6A
1POL 5SX2
SPARE
140 00342916-01 POWER CABLE: POWER
141 00301769-02 SHEET METAL ANGLE
142 00322063-01 INTERFACE COMPONENTS SUPPLY SPARE PART
143 00322239-01 BASE HOUSING F. SS
(COMPONENTS SUPPLY)
144 00321428-01 CABLE: CONTROL UNIT-INTERFACE
(LEFT)
145 00322067-02 CABLE: TERMINAL BOARD -
INTERFACE LEFT SIDE
146 00322071-02 CABLE: INTERFACE - TAPE CUTTER
LEFT SIDE
147 00322069-01 CABLE: TERMINAL BOARD -
INTERFACE LEFT SIDE
148 00312358-01 PNEUMATIC CONNECTION CO
TABLE
SPARE PART
149 00309452-01 BLOCK
150 00200242-01 COUPLER SOCKET SPARE PART
151 00201148S01 SEALING RING M5 PVC HARD WEAR PART
152 00047028-01 PLUG-IN NIPPLE N-M5-PK-4
153 00095034-01 HEXAGON SOCKET HEAD CAP
SCREW M5 X 12-8.8
154 00309449-01 LOCK WASHER
155 00309451-05 ANGLE (INTERFACE)
156 00322064-01 INTERFACE COMPONENTS RIGHT
SIDE
SPARE PART
157 00322239-01 BASE HOUSING F. SS
(COMPONENTS SUPPLY)
158 00321429-01 CABLE: CONTROL UNIT-INTERFACE
(RIGHT)
159 00322068-02 CABLE: TERMINAL BOARD -
INTERFACE RIGHT SIDE
160 00322072-02 CABLE: INTERFACE - TAPE CUTTER
Machine frame SIPLACE 80 F5
Page 30 / 31 19.11.2021
Pos. Item no. Description Part marking
161 00322070-01 CABLE: TERMINAL BOARD -
INTERFACE RIGHT SIDE
162 00312358-01 PNEUMATIC CONNECTION CO
TABLE
SPARE PART
163 00309452-01 BLOCK
164 00200242-01 COUPLER SOCKET SPARE PART
165 00201148S01 SEALING RING M5 PVC HARD WEAR PART
166 00047028-01 PLUG-IN NIPPLE N-M5-PK-4
167 00095034-01 HEXAGON SOCKET HEAD CAP
SCREW M5 X 12-8.8
168 00309449-01 LOCK WASHER
169 00309451-05 ANGLE (INTERFACE)
170 00322104-01 INTERFACE WP-COMPONENTS
SUPPLY LEFT SIDE
171 00322240-01 BASE HOUSING F. SS (WPC)
172 00322107-01 CABLE: CONTROL UNIT-INTERFACE
(LEFT)
173 00322109-02 CABLE: TERMINAL BOARD -
INTERFACE
174 00322111-01 CABLE: TERMINAL BOARD -
INTERFACE
175 00300493-02 ANGLE
176 00322105-01 INTERFACE WPC-COMPONENTS
UNIT
Spare Part
177 00322240-01 BASE HOUSING F. SS (WPC)
178 00322108-01 CABLE: CONTROL UNIT-INTERFACE
(RIGHT)
179 00322110-02 CABLE: TERMINAL BOARD -
INTERFACE
180 00322112-01 CABLE: TERMINAL BOARD -
INTERFACE
181 00300493-02 ANGLE
182 00321190-03 CONVERSION BOARD GANTRY SPARE PART
183 00304188-01 MOUNTING FOOT 22*4,3*14 STANDARD PARTS
184 00320817-02 HINGED PLATE SPARE PART
187 00321439-03 CONTROL UNIT - CONVERSION
BOARD PORTAL
188 00321536-02 CABLE: TRACK (Y-AXIS)
189 00321537-01 CABLE: MOTOR/TACHO X-AXIS
Machine frame SIPLACE 80 F5
Page 31 / 31 19.11.2021
Pos. Item no. Description Part marking
190 00321538-02 CABLE: TRACK (X-AXIS)
191 00321539-01 CABLE: MOTOR DR-AXIS
SP/IC1-HEAD
192 00321540-02 CABLE: TRACK SIGNALS DR-AXIS
SP/IC1-HEAD
193 00321541-03 CABLE: MOTOR/TACHO Z-AXIS
SP/IC1-HEAD
194 00321542-02 CABLE: TRACK SIGNALS Z-AXIS
SP/IC1-HEAD
195 00321544-03 CABLE: MOTOR/TACHO DP1-AXIS
W1/W2
196 00321546-03 CABLE: TRACK SIGNALS DP1-AXIS
197 00321547-03 CABLE: CRASH-BEROS
198 00321548-02 CABLE: CONTROL UNIT-
CONVERSION BOARD
Spare Part
199 00321585-04 CABLE CAN-BUS GANTRY 1
200 00321587-03 CABLE: CRASH-SIGNAL (TERMINAL
BD CONV.)
201 00321787-02 CABLE: VOLTAGE STAR-MOTOR
PORTAL 1
202 00321789-02 CABLE: VOLTAGE ILLUMINATION
PORTAL 1
203 00321898-03 CABLE: CONTROL UNIT -
CONVERSION BOARD P
204 00321899-01 CABLE: TRACK SIGNALS Z-AXIS IC2
205 00322256-01 CABLE FOR PORTAL SPARE PART
206 00322257-01 CABLE FOR PORTAL HEAD AXIS SPARE PART
207 00322258-01 CABLE FOR PORTAL CAN BUS SPARE PART
208 00322259-01 CABLE FOR PORTAL DP1-AXIS SPARE PART
209 00322261-01 CABLE FOR PORTAL STAR/Z-AXIS SPARE PART
210 00322262-01 CABLE FOR PORTAL X-MOTOR SPARE PART
211 00322264-01 CABLE FOR PORTAL X-MOTOR/Y-
TRACK
SPARE PART
212 00322265-02 GANTRY CABLE IC2-HEAD SPARE PART
213 00321900-02 CABLE: TRACK SIGNALS DR-AXIS
IC2
