User Manual SIPLACE S-25 HM 3 What to do when ...
Software Version SR.503.xx 04/2002 US Edition
101
3 What to do when ...
This chapter contains a number of subjects that are intended to help you during your daily work on
a SIPLACE line.
For example, you are provided with preventative measures that you can take to minimize the down
time on the machine to obtain the highest possible level of efficiency for the SIPLACE line during
production.
In addition, the tasks of the operator and of the line engineer are described in an operator and line
engineer profile, respectively, in this chapter.
3 What to do when ... User Manual SIPLACE S-25 HM
3.1 Switching on the SIPLACE line Software Version SR.503.xx 04/2002 US Edition
102
3.1 Switching on the SIPLACE line
3.1.1 Switching on the line computer (UNIX) / starting the user interface of the line
computer program
Æ Switch on the uninterruptible power supply (UPS).
The line computer software is uploaded.
The login dialog window appears on the screen after approximately 2 minutes.
Æ Enter plr in the "login" box and confirm your entry by pressing the RETURN key.
Æ Enter the password in the "Password" box and press the RETURN key. If no password is re-
quired, then just press the RETURN key
The desktop (starting window) will appear on screen after approximately 3 minutes with the
overlying login box.
Æ Enter the user name defined for your user account in the "User" box, and enter the correspond-
ing password in the "Password" box.
Æ Click on Ok to confirm. The functions of the line computer program can now be executed ac-
cording to your access rights.
3.1.2 Switch on line computer (Windows NT with SIPLACE Pro line software)
/start up the SIPLACE Pro user interface
Æ Switch the line computer on. Once the computer has started up, the Windows NT log-in win-
dow appears.
Æ Enter your user name and password to log into your domain.
Æ From the Windows NT Start menu, start SIPLACE Pro by selecting:
Start
→ Programs → Siemens SIPLACE entry
or
click on the icon on the desktop to start SIPLACE Pro.
The system connects to the SIPLACE Pro server and starts the SIPLACE Pro user interface.3
User Manual SIPLACE S-25 HM 3 What to do when ...
Software Version SR.503.xx 04/2002 US Edition 3.1 Switching on the SIPLACE line
103
3
Fig. 3.1 - 1 Starting SIPLACE Pro
3.1.3 What you should check before switching on the stations
ATTENTION
Carry out the steps described in the following before you switch on the stations. 3
Æ Check to make sure that the stations are connected to power and to the compressed air supply.
Æ Carry out a visual inspection of the stations. In particular, make sure that there are no obstruc-
tions in the traveling range of the gantries.
Æ Make sure that the Z-axes of all the heads are in the top end position.
Æ Close the feeder covers and the protective covers.
Æ Make sure that there is no diskette in the floppy drive of the station computer.
