5 Station extensions
5.1 Nozzle changer for the 12-segment Collect&Place
head
5.1.1 Overview
The placement system is supplied as standard with two Collect&Place heads. As an option, a noz-
zle changer can be installed for each Collect&Place head. This enables the nozzle configuration
to be changed quickly, thus allowing the Collect&Place head to be quickly adapted to the needs
of the placement process. 5
The nozzle changer consists of at least one, and up to eight magazines, each with twelve nozzle
garages (see Fig. 5.1 - 1). The magazines are seated on a common support and each magazine
is centered using two parallel pins and fixed in place with a spring hook. 5
NOTE:
Please refer to Section 5.9 on page 193 for information on the the nozzle changer for the 6-seg-
ment Collect&Place head. 5
5.1.2 Technical data
5
Nozzle changer for the 12-segment Collect&Place head
Dimensions (length x width x height) 282 mm x 214 mm x 107 mm
Number of nozzle garages Min. 12 / max. 96
Nozzle types 9xx
Time required to open and close the locking plate < 200 ms
Capacity of the reject bin Approx. 50 nozzles
Pneumatic circuit Compressed air line 5.3 bar
5 Station extensions User Manual SIPLACE S-25 HM
5.1 Nozzle changer for the 12-segment Collect&Place head Software Version SR.503.xx 04/2002 US Edition
160
Fig. 5.1 - 1 Nozzle changer for the 12-segment Collect&Place head, overview
5
(1) Magazine
(2) Nozzle discarding device
(3) Container for discarded nozzles
(4) Nozzle changer base
