User Manual SIPLACE S-25 HM 1 Introduction, technical data

Software Version SR.503.xx 04/2002 US Edition 1.11 Overview of the modules - controls

1.11.2 Description

All the controls can be reached by a 1.60 m tall person. 1

Main switch 1

The main switch is used to switch the power supply to the placement system on and off. 1

RISK OF DEATH

Some parts inside the placement system carry potentially lethal voltages - even when switched off

at the main switch. 1

Key switch 1

In normal mode, the key switch is set to "0". The key should be removed and kept in a safe place.

It must only be turned to position "I" (set-up mode) by authorized personnel, and then only for cer-

tain maintenance and servicing work. 1

Stop button 1

This button is used to stop the placement system. 1

Start button 1

This button starts the placement system after it has been switched on or after faults have been

eliminated. 1

EMERGENCY STOP mushroom-head push-button 1

The emergency stop mushroom-head push-button latches in the ON position when pressed. The

power supply to the gantry axes, the components change-over tables, conveyors, and used tape

cutters is interrupted and the voltage supplied to the star axes of the placement heads is reduced.

Turn the button to release it. 1

Component counter 1

The component counter displays the number of components processed. 1

Station computer, monitor and keyboard 1

The station computer, monitor and keyboard are mounted on a pivoting console on the placement

system’s central cross-beam. The station computer is a desktop model with a Pentium processor.

The operating system is WINDOWS NT 4.0. The SIPLACE graphical user interface, which is

based on the Windows standard, is used to operate and monitor the placement system.

1 Introduction, technical data User Manual SIPLACE S-25 HM

1.11 Overview of the modules - controls Software Version SR.503.xx 04/2002 US Edition

A 15" color touch screen monitor with a resolution of 1024 x 768 pixels provides the screen dis-

play. Both the keyboard and the touch screen can be used to enter data, and the ultra-flat IBM-

compatible PC keyboard incorporates a trackball for controlling the mouse. 1

Indicator lamps 1

The sequence of colors is white - green - white. These lamps are used to signal operating statuses

and malfunctions of the placement system. 1

Component barcode reader 1

There is a compartment for the Datalogic DL 910 component barcode reader between the monitor

and keyboard. The barcode reader enables the components to be set up and topped up quickly

and reliably. 1

1.11.3 Ergonomic arrangement of the controls

Figure 1.11 - 1 on page 32 provides an overview of the position of the controls, which are subdi-

vided into the following groups: 1

Operating panel on the PCB input side with 1

– Start button

– Stop button

– Emergency stop mushroom-head push-button

– Main switch (on the left-hand side)

Operating panel on the PCB output side with 1

– Emergency stop mushroom-head push-button

– Start button

– Stop button

– Component counter

–Key switch

Console on the central cross-beam with 1

– Station computer

– Touchscreen

– Keyboard and

– Component barcode reader (option)

User Manual SIPLACE S-25 HM 1 Introduction, technical data

Software Version SR.503.xx 04/2002 US Edition 1.11 Overview of the modules - controls

1.11.3.1 Controls on the input and output sides of the placement system

The controls on the input and output sides of the placement system perform identical functions.1

Emergency stop mushroom-head push-button and Start and Stop buttons 1

There is an emergency stop mushroom-head push-button, a Start button and a Stop button on

both the input and output sides of the PCB conveyor. This arrangement was adopted for the emer-

gency stop mushroom-head push-buttons because it enables them to be reached quickly and

easily from any position. 1

In addition, it is important to have an unrestricted view of the placement heads and placement area

during maintenance, servicing and setting up work in order to be able to check all the operations

carried out inside the machine. This particularly important during testing phases or when starting

single functions, for example. 1

Key switch 1

The key switch is located on the operating panel on the PCB output belt. It is only needed for set-

ting up and servicing work so, for reasons of efficiency, it is positioned near the Start and Stop but-

tons. 1

Main switch 1

The main switch is part of the power supply unit, so it is positioned on the left-hand side of the

PCB input belt. It is located here because it is only needed for servicing and maintenance work

and is therefore not subject to frequent use. 1

1.11.3.2 Controls on the placement system console

Station computer, monitor and keyboard 1

The station computer, monitor and keyboard are all mounted on the console. They are arranged

so that any person who is at least 1.60 m tall can work comfortably and efficiently. 1

Component barcode reader 1

The two component tables for supplying components are arranged on the right and left of the

placement system. For this reason, the component barcode reader is also located in the central

console, since it enables the operators to work comfortably and efficiently during the component

set-up and filling checks. 1
