User Manual SIPLACE S-25 HM 2 Operational Safety Software Vers ion SR.503.xx 04/2002 US Edition 2.1 Safety instruc tions 57 Item 5 in f igure 2.1 - 1 show ing the warning s igns on the basic mac hine 2 2 Item 6 in f igur…
2 Operational Safety User Manual SIPLACE S-25 HM
2.1 Safety instructions Software Version SR.503.xx 04/2002 US Edition
56
Item 3 in figure 2.1 - 1 showing the warning signs on the basic machine 2
RISK OF CRUSHING HANDS
IF THE PROTECTIVE COVERS ARE NOT CLOSED CORRECTLY 2
Item 4 in figure 2.1 - 1 showing the warning signs on the basic machine 2
Nicht in die laufende
Maschine greifen
Do not put your
hands into working
machine
Ne pas mettre les
mains dans la machine
en fonctionnement
Non mettere le mani
nella macchina durante
il funzionamento
User Manual SIPLACE S-25 HM 2 Operational Safety
Software Version SR.503.xx 04/2002 US Edition 2.1 Safety instructions
57
Item 5 in figure 2.1 - 1 showing the warning signs on the basic machine 2
2
Item 6 in figure 2.1 - 1 showing the warning signs on the basic machine 2
2
Item 7 from diagram 2.1 - 1 concerning the warn-
ing labels on the basic machine (tape cutters)
2
VORSICHT NETZSPANNUNG
Vor Abnehmen der Schutzabdeckung
Netz vollständig abschalten
Kondensatorentladezeit
tmin. = 0,25 Minuten abwarten
WARNING! MAIN POWER VOLTAGE!
Completely isolate the machine
before removing the protective cover.
Capacitor discharge time
tmin. = wait 0.3 minutes
Vor dem Eingreifen
Automaten von der
Netz- und Druckluft-
versorgung trennen
Disconnect machine from
main power and compressed
air supply before servicing
2 Operational Safety User Manual SIPLACE S-25 HM
2.1 Safety instructions Software Version SR.503.xx 04/2002 US Edition
58
Fig. 2.1 - 2 Warning signs on the basic machine - part 2
(1) Main power switch
T Direction of PCB transport 2
2
Item in figure 2.1 - 2 showing the warning signs on the basic machine 2
Danger!
All correspondingly marked
parts remain electrically
live and dangerous even
when the main switch is off!
