2.1.6 Additional warning signs for the NAFTA region
The following figure shows the positions of the warning labels on the machine. They are made
from soft PVC film, and are abrasion-proof, light-fast and resistant to water and weathering. 2
The graphical symbols on the warning label correspond to the symbols defined in DIN 4844 and
SEMI S1-90, © SEMI 1986, 1996. 2
WARNING 2
Æ Make sure that the warning labels are always clearly identifiable and easily readable.
Æ Replace any damaged or illegible warning or notice labels.
Æ Replace any labels that are missing.
Fig. 2.1 - 4 Warning signs on the basic machine - NAFTA region
User Manual SIPLACE S-25 HM 2 Operational Safety
Software Version SR.503.xx 04/2002 US Edition 2.1 Safety instructions
63
Item 1 in Fig. 2.1 - 4 showing the warning signs on the basic machine - NAFTA region 2
Item 2 in Fig. 2.1 - 4 showing the warning signs on the basic machine - NAFTA region 2
Item 3 in Fig. 2.1 - 4 showing the warning signs on the basic machine - NAFTA region (on the cover
over the terminal panels) 2
Warning
High voltage
can cause
severe
injury or death
Operating
machinery can
crush and
mutilate limbs
Cutting tools
can slice or
sever limbs
Service in this area must be performed by
authorized personell only
Switch off main electrical and pneumatic
switches, remove from main power
Warning !
Hazardous voltages present
even when
EMERGENCY STOP
is pressed
2 Operational Safety User Manual SIPLACE S-25 HM
2.1 Safety instructions Software Version SR.503.xx 04/2002 US Edition
64
2
2
2
2
2
2
2
Item 4 in Fig. 2.1 - 4 showing the warning signs on
the basic machine - NAFTA region 2
2
2
2
2
2
2
2
2
2
2
Item 5 in Fig. 2.1 - 4 showing the warning
signs on the basic machine - NAFTA region -
visible when the covers are open 2
Warning
High voltage can cause
severe
injury or death
Service in this area must be performed by
authorized personell only
Switch off main electrical and pneumatic
switches, remove from main power
Operating machinery
can
crush and mutilate limbs
Warning
Sliding covers
can crush or cut
