Assembly and User Manual 1 Introduction Shuttle Extension Edition 06/2017 1.2 Overview 9 1.2.3 Configuration Example 1 Fig. 1.2 - 3 Shuttle Extensi on TX - Configuration Example (1) Shuttle Extension TX on SIPLACE TX inp…
1 Introduction Assembly and User Manual SIPLACE TX
1.2 Overview Shuttle Extension Edition 06/2017
8
1.2.2 Shuttle Extension TX on SIPLACE TX Input Conveyor Side
1
Fig. 1.2 - 2 Shuttle Extension TX output side on SIPLACE TX input conveyor side
(T) Direction of travel to SIPLACE TX input conveyor
(1) Start- and Stop button
(2) EMERGENCY STOP button
(3) Top cover
(4) Side covers
(5) Interface brackets on SIPLACE TX input conveyor side
(1)
(5)
(2)
(3)
(4)
Assembly and User Manual 1 Introduction
Shuttle Extension Edition 06/2017 1.2 Overview
9
1.2.3 Configuration Example
1
Fig. 1.2 - 3 Shuttle Extension TX - Configuration Example
(1) Shuttle Extension TX on SIPLACE TX input conveyor
(2) Shuttle Extension TX on SIPLACE TX output conveyor
(3) SIPLACE TX placement machine
(1)
(2)
(3)
1 Introduction Assembly and User Manual SIPLACE TX
1.2 Overview Shuttle Extension Edition 06/2017
10
1.2.4 Machine serial number
The serial number of the machine can be found on the type plate (1), on the side cover of the
SIPLACE Shuttle Extension.
1
Fig. 1.2 - 4 Position of type plate with serial number
(T) Direction of travel
(1) Type plate
(1)
