Assembly and User Manual 1 Introduction Shuttle Extension Edition 06/2017 1.2 Overview 11 1.2.5 EC Declaration of conformity The product/device d escribed below Manufactured by ASM Assembly Systems Singapore Pte Ltd 535 …
1 Introduction Assembly and User Manual SIPLACE TX
1.2 Overview Shuttle Extension Edition 06/2017
10
1.2.4 Machine serial number
The serial number of the machine can be found on the type plate (1), on the side cover of the
SIPLACE Shuttle Extension.
1
Fig. 1.2 - 4 Position of type plate with serial number
(T) Direction of travel
(1) Type plate
(1)
Assembly and User Manual 1 Introduction
Shuttle Extension Edition 06/2017 1.2 Overview
11
1.2.5 EC Declaration of conformity
The product/device described below
Manufactured by
ASM Assembly Systems Singapore Pte Ltd
535 Yishun Industrial Park A
ASM Tech-Park Building 2
Singapore 768775 1
1
conforms to the regulations and standards listed in the EU Declaration of Conformity provided.
1.2.6 Use as prescribed
The product may only be used for the areas of application specified in the catalogues and techni
-
cal descriptions and may only be used together with the third party devices and components rec
-
ommended or approved by ASM Assembly Systems GmbH & Co. KG. Use for a different or
extended purpose is not prescribed.
In the case of incorrect usage, ASM Assembly Systems GmbH & Co. KG will not assume liability
for any damage which occurs and will not guarantee the correct and proper function of machine
components.
Use as prescribed also includes compliance with all the instructions in the user manual.
For the product to operate correctly and reliably, it must have been transported, stored, erected
and assembled correctly and must be operated and maintained with care.
Product Item no.
Shuttle Extension TX 588508-xx
Shuttle Extension TX + Barcode Option 588509-xx
1 Introduction Assembly and User Manual SIPLACE TX
1.2 Overview Shuttle Extension Edition 06/2017
12
1.2.7 Failure to use as prescribed
Failure to use the product as prescribed can result in both danger to life and limb and material
damage. For this reason, used other than as prescribed is expressly prohibited. In the case of in
-
correct usage, ASM Assembly Systems GmbH & Co. KG will not assume liability for any damage
which occurs and will not guarantee the correct and proper function of machine components.
Use of the machine other than as prescribed includes, for example
– Operation of the Shuttle Extension TX with safety equipment deactivated or removed.
– Use of unauthorized accessories and additional modules.
– Use of the Shuttle Extension TX by unqualified personnel.
– Operation of the placement machine without a hand guard on the board conveyor.
– Persons standing on the top lid and cover plates.
– The use of wet cleansing tissues
