Assembly and User Manual 2 Operational safety Shuttle Extension Edition 06/2017 2.2 Warning labels 25 Fig. 2.2 - 4 Warning labels inside the Shuttle Extension TX - pa rt 2 (1) Warning strips on the hand guard Item W 203,…

100%1 / 88
2 Operational safety Assembly and User Manual
2.2 Warning labels Shuttle Extension Edition 06/2017
24
Fig. 2.2 - 3 Warning labels inside the Shuttle Extension TX - part 1
(1) Ground
(T) Direction of PCB transport
(1)
Assembly and User Manual 2 Operational safety
Shuttle Extension Edition 06/2017 2.2 Warning labels
25
Fig. 2.2 - 4 Warning labels inside the Shuttle Extension TX - part 2
(1) Warning strips on the hand guard
Item W 203, item no. 03009342-xx
2
WARNING
Damage to warning labels!
The warning labels can be damaged or destroyed by abrasive cleaning agents or sol
-
vents.
Do not use abrasive cleaners or solvents for cleaning warning labels.
Replace any damaged or illegible warning labels.
(1)
W 203
W 203
2 Operational safety Assembly and User Manual
2.2 Warning labels Shuttle Extension Edition 06/2017
26
2.2.1 Warning label W 203
2
W 203 in fig. 2.2 - 1, page 22, 2.2 - 2, page 23 and 2.2 - 4, page 25, item no. 03009342-01
(Quantity per Shuttle Extension TX: 8)
2.2.2 Warning label W 204
2
W 204 in fig. 2.2 - 1, page 22 and 2.2 - 2 page 23, Item no. 03009343-01
(Quantity per Shuttle Extension TX: 2)
2.2.3 Warning label W 210
2
W 210 in fig. 2.2 - 1, page 22, item no. 03009350-01
(Quantity per Shuttle Extension TX: 1)
2
2
2
Danger of crushing
Reaching in here can lead to injuries to the arms and hands.
Do not reach into the Shuttle Extension TX while it is running.
Do not reach into the inside of the neighboring machine.
2
2
2
Danger of crushing
Reaching in here can lead to injuries to the arms and hands.
Do not reach into the Shuttle Extension TX while it is running
2
2
2
2
2
2
Warning label on the EMERGENCY STOP button
