3 Power Supply
53
CAUTION
Ensure that the cables do not become trapped, otherwise the insulation will be damaged.
➠ Fix the fixing bar in place.
➠ Complete the servicing work as described in 3.3.3 on page 3 - 29.
5HSODFLQJUHFWLILHU9DQG9
7RROVDQGHTXLSPHQW
– Set of slotted-head screwdrivers
– Open-ended spanner or socket spanner, size 8
– Self-adhesive labels
– Heat transfer compound
– Digital multimeter
– HS-50 detailed circuit diagrams
3DUWV
V1, V7 rectifier S101-B6U-160-08, item number 00341246-01
5HPRYLQJWKHUHFWLILHU
DANGER Switch off the placement system and disconnect from the power
supply (see sections 3.3.1 and 3.3.2).
07/2002 Edition Student Guide HS-50 Advanced II
3 Power Supply
54
➠ Loosen the M5 fillister head screws (1).
➠ Remove the retaining rings (2).
➠ Remove the perspex cover (3)
➠ Loosen the terminal wire screw connections (4) one by one and identify with self-adhesive la-
bels.
➠ Loosen the hexagon screw bolts (5).
➠ Loosen the M5 nuts (6).
➠ Remove the lock washer (7).
➠ Remove the rectifier (8).
➠ Remove residue of heat transfer compound from the surfaces of the unit.
)LWWLQJUHFWLILHU9DQG9
➠ Apply heat transfer compound to the "metal side" of the rectifier.
➠ Fit the rectifier (8).
➠ Fit the lock washer (7) and fix to the rectifier with an M5 hexagon nut (6).
➠ Attach the hexagon screw bolts (5).
➠ Connect the terminal wires (4) (ensure that the polarity is correct).
➠ Switch the placement system on and start it up.
➠ Use the digital voltmeter to measure the voltages shown in the "Voltages at rectifiers V1 - V8"
table on page 3 - 16
.
Student Guide HS-50 Advanced II 07/2002 Edition
3 Power Supply
55
DANGER Switch off the placement system and disconnect from the power
supply (see sections 3.3.1 and 3.3.2).
➠ Fix the perspex panel to the rectifier.
PLEASE NOTE:
Do not overtighten the M5 fillister head screws, otherwise the panel might break.
➠ Complete the servicing work as described in 3.3.3 on page 3 - 29.
5HSODFLQJUHFWLILHU99999RU9
7RROVDQGHTXLSPHQW
– Open-ended spanner or socket spanner, size 10
–Pliers
– Self-adhesive labels
– Heat transfer compound
– Digital multimeter
– HS-50 detailed circuit diagrams
3DUWV
5HPRYLQJUHFWLILHU9WR9DQG9
DANGER Switch off the placement system and disconnect from the power
supply (see sections 3.3.1 and 3.3.2).
3RVLWLRQ 'HVLJQDWLRQ ,WHPQXPEHU
V2 Rectifier S61-B2U 28-02 00341244-01
V3 - V6, V8 Rectifier S63-B6U 28-02 00341245-01
