LF3-191 1 Rev . :It had a change without the compatibility . Please be careful at the time of the parts ordering. Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。 No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. P…
LF3-1911
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 LE6-M65E1-10 ANC SENSOR ASSY. 2 B
Í
39
2 LE6-M7808-E0 SHAFT,CLAMP 1 /
Í
40
3 LE6-M780F-E0 PIN 40 /
Í
41
4 LE6-M78A1-00 ANC SV.ASSY 1 B
Í
42
5 LE6-M78A2-00 CYLINDER 1 B
Í
43
6 LE6-M78A3-00 TUBE 1 /
Í
44
7 LE6-M78A4-00 TUBE 1 /
Í
45
8 LE6-M78F1-E0 SPACER 18 /
Í
46
9 LE6-M78F1-F0 SPACER 2 /
Í
47
10 LE6-M78F3-00 WASHER 18 /
Í
48
11 LF3-M7801-00 BLOCK(40) 1 /
Í
49
12 LF3-M7803-00 SHUTTER,PLATE(40) 1 /
Í
50
13 LG0-M78A4-10 CTRL.SPEED 2 /
Í
51
14 LG0-M78A7-00 JOINT 2 /
Í
52
15 LG0-M78A8-10 SILENCER 2 /
Í
53
16 LG9-M12A8-00 JOINT,ELBOW 1 /
Í
54
17 90169-02J206 SCREW, BINDING HEAD 20 55
18 90200-20J070 O-RING 1 56
19 90944-20J000 BALL STEEL 4 57
20 91312-03008 BOLT HEX,SOCKET HEAD 2 58
21 91312-03030 BOLT HEX,SOCKET HEAD 4 59
22 91312-08025 BOLT HEX,SOCKET HEAD 4 60
23 92990-08200 WASHER,PLAIN 4 61
24 92A08-05006 SCREW,SET 1 62
25 63
26 64
27 65
28 66
29 67
30 68
31 69
32 70
33 71
34 72
35 73
36 74
37 75
38 76
6
3
Nozzle Changer 40
