Introduction

Other Instructions 1.3.4 Release History

50 Extension Input/Output Conveyor and Hand Guard Ein-/

1.3.3.3

1.3.3.3 Handling ESD Modules

Handling ESD Modules

Do not touch electronic modules unless it is absolutely essential to do so in order to carry out other work.

If it is necessary, make sure that you do not touch the pins or printed conductors when you pick up flat

modules.

Do not touch components unless

▪ You are constantly earthed by an ESD wrist strap or

▪ You are wearing ESD shoes or ESD shoe earthing strips on an ESD floor.

Always discharge yourself before you touch an electronic module. To do this, simply touch a conductive

and earthed object immediately before you touch the module (such as unpainted parts of a switch cab-

inet, a water pipe, etc.).

Do not allow modules with chargeable and highly insulating materials to touch one another, e.g. plastic

films, insulating table surfaces or items of clothing made from synthetic fibers.

Always place the modules on a conductive surface (table with an ESD coating, conductive ESD foam,

ESD bag or container).

Do not bring modules near visual display units, monitors or televisions. Keep them at least 10 cm away

from the screen.

1.3.3.4

1.3.3.4 Measurements and Modifications to ESD Modules

Measurements and Modifications to ESD Modules

Measurements of the assemblies may only be taken if

▪ The measuring device has been grounded (e.g. via protective conductor) or

▪ The measuring head of the potential-free measuring device has been briefly discharged before

measurement (e.g. touching blank metal control unit housing).

► Always use an earthed soldering iron if you carry out any soldering work.

1.3.3.5

1.3.3.5 Dispatching ESD Modules

Dispatching ESD Modules

► Always store modules and components in conductive packaging (e.g. metallized plastic bags or met-

al sleeves) and dispatch them in conductive packaging.

► If the packaging is not conductive, place the modules in a conductive envelope before packaging.

Use conductive foam rubber, ESD bags, domestic aluminum foil or paper, for example. NEVER use

plastic bags or film.

► If the module has integral batteries, ensure that the conductive packaging does not touch or short-

circuit the battery terminals and, if necessary, first cover the terminals with insulating tape or mate-

rial.

1.3.4

1.3.4 Release History

Release History

Release Changes

04/2013 First edition

08/2013 Additional texts (Torx TX25, Sirio)

Introduction

1.3.5 SIPLACE on the World Wide Web (WWW) Staff Qualifications and Training

Extension Input/Output Conveyor and Hand Guard Ein-/Ausgabebandverlängerung und Eingreifschutz 51

1.3.5

1.3.5 SIPLACE on the World Wide Web (WWW)

SIPLACE on the World Wide Web (WWW)

Log into our SIPLACE

homepage at http://www.siplace.com.

► You can choose between the German and English versions.

The different sections contain information about our products, services and contact persons.

In addition, registered customers can also access the

SIPLACE User Group

. Here you can call up spe-

cial information about our placement systems e.g.

▪ Technical documentation,

▪ Technical information,

▪ Spare parts lists etc.

Registration for the user group is very simple:

► Click on the Register link.

► Fill in the registration form and send it off to us.

Soon afterwards, you will receive your access authorization with USER ID and password.

1.4

1.4 Staff Qualifications and Training

Staff Qualifications and Training

Qualified or adequately trained personnel means that these people are familiar with the setting up, op-

eration and maintenance of automatic placement systems and add-on devices and are suitably qualified,

e.g.:

▪ Have been trained, instructed or authorized to switch on and off, isolate, earth and identify electrical

circuits and system components in accordance with normal safety standards.

▪ Have been trained or instructed in the upkeep and use of appropriate safety equipment in accord-

ance with normal safety standards.

▪ Have received first aid training.

Introduction

Abbreviations 1.3.5 SIPLACE on the World Wide Web (WWW)

52 Extension Input/Output Conveyor and Hand Guard Ein-/

1.5

1.5 Abbreviations

Abbreviations

Abbreviations Description

PA, PA1, PA2 Placement area, Placement area 1, Placement area 2

CO Component

COT Changeover table

COT-i Changeover table insert

C&P Collect&Place

C&P12, CP12 Collect&Place head with 12 segments

C&P20, CP20 Collect&Place head with 20 segments

C&P6, CP6 Collect&Place head with 6 segments

CPP Collect&Pick&Place head

CPx Collective term for CPP, CP20, CP12 and/or CP6

DC Dual conveyor with 2 lanes

ESD Electrostatic sensitive device

EMC Electromagnetic compatibility

SC Single conveyor with 1 lane

FHE Fast Head Exchange

PCB Board

P&P Pick&Place

QC Quad lane conveyor with 4 lanes

SCS Single Core Solution

SC Station computer

TH TwinHead

VS Vision system type

WPC Wafflepack Changer

WPC4/5/6 Waffle Pack Changer Version 4/5/6

ID Intermediate distributor

ID1, ID2 Intermediate distributor 1, intermediate distributor 2
