3 TYPHOON UNDER STENCIL CLEANER 3.4 ELECTRICAL SCHEMATIC STANDALONE MANUAL TYPHOON UNDER STENCIL CLEANER 06/2020 23 Part M37 Power Supply M37PL35 L N E Part I/O Node 4 Part M36 Control Enclosure M36PL9 9SK69 9PL69 Servic…
3 TYPHOON UNDER STENCIL CLEANER
3.4 ELECTRICAL SCHEMATIC
22 STANDALONE MANUAL TYPHOON UNDER STENCIL CLEANER 06/2020
Part
I/O Node 4
N4SK1
0V Return
+24V US
+24V SW
0V Return
+12V
0V Return
Node
Power
N4SK2
CAN_L
CAN_H
CAN GND
CAN
In
N4SK3
CAN_L
CAN_H
CAN GND
CAN
Out
Plenum Down Left
Solid State
Reed Switch
8SE108
Plenum Down Right
Solid State
Reed Switch
8SE107
N4PL8
+12V
DIG IN 4
0V Return
+12V
DIG IN 5
0V Return
Under Stencil
Cleaner Drag
Chain
Plenum Up Left
Solid State
Reed Switch
8SE110
Plenum Up Right
Solid State
Reed Switch
8SE109
N2PL4
DIG OUT 14
0V Return
Plenum Lift
Solenoid
16SOL08
16SK08
Part Main Machine
I/O Node 2
N2SK1
0V Return
+24V US
+24V SW
0V Return
+12V
0V Return
Node
Power
N2SK2
CAN_L
CAN_H
CAN GND
CAN
In
N2SK3
CAN_L
CAN_H
CAN GND
CAN
Out
Plenum Lift Sense Option (Standard USC only)
DIG OUT 13
0V Return
Fabric Roll
Brake
16SOL06
16SK06
Typhoon Schematic - Sheet 2 of 3
3 TYPHOON UNDER STENCIL CLEANER
3.4 ELECTRICAL SCHEMATIC
STANDALONE MANUAL TYPHOON UNDER STENCIL CLEANER 06/2020 23
Part M37 Power Supply
M37PL35
L
N
E
Part
I/O Node 4
Part M36
Control Enclosure
M36PL9 9SK69 9PL69
Service Panel
AN IN0+
AN IN0-
0V USR
+12V
-12V
9SK/9PL63
Optional
Solvent Level
Amplifier
9SK/9PL64
Solvent Tank Weigh
Single Point Load Cell
9SE26
Solvent ‘Time To Go’ Option
E By DEK Variation
Solvent Float
Sensor
9SE69
9PL69 9SK/9PL130
Output
0V
+V
Vacuum Filtration
Unit
N4PL6
Venturi Vacuum
Solenoid
8SOL29
8SK60
N4PL6
Venturi Vacuum Filtration Option
M35SK1
N4PL10
P P
Low Pressure
Switch
High Pressure
Switch
DIG IN 6
0V Return
DIG IN 7
0V Return
M35SK/M35PL3
USC Vacuum Sensing Option
M35SK2
Typhoon Schematic - Sheet 3 of 3
3 TYPHOON UNDER STENCIL CLEANER
3.5 PNEUMATIC SCHEMATIC
24 STANDALONE MANUAL TYPHOON UNDER STENCIL CLEANER 06/2020
3.5 PNEUMATIC SCHEMATIC
The pneumatic supplies for the USC lift actuators and fabric roll clamp are supplied via two solen-
oid valves fitted to the printer's rear pneumatic manifold (illustrated below).
A AB B
O
S
16SOL08
PLENUM LIFT
FABRIC ROLL BRAKE
16SOL06
