4 STANDALONE MANUAL TYPHOON UNDER STENCIL CLEANER 06/2020 TABLE OF CONTENTS 4 TYPHOON SOFTWARE 51 4.1 SOFTWARE SETUP 51 5 CIRCUIT DRAWINGS 55 5.1 LIST OF DRAWINGS 55
3STANDALONE MANUAL TYPHOON UNDER STENCIL CLEANER 06/2020
TABLE OF CONTENTS
TABLE OF CONTENTS
1 MANUAL INFORMATION 5
1.1 MANUAL SCOPE 5
1.2 MANUAL CHANGE REQUEST 5
2
SAFETY INFORMATION 7
2.1 SOLVENT ADVICE 7
2.2 RECOMMENDED SOLVENTS 8
3
TYPHOON UNDER STENCIL CLEANER 9
3.1 OVERVIEW 9
3.2 USC ASSEMBLIES 12
3.2.1 USC Base Unit 12
3.2.2 Lift Mechanism Assembly 14
3.2.3 Fabric Roll Assembly 15
3.2.4 Plenum Chamber And Interchangeable Inserts 16
3.2.4.1 Hard Top Insert 18
3.2.4.2 Poly Blade Insert 18
3.2.4.3 Duo Insert 18
3.2.5 Solvent Pump And Supply 18
3.2.6 Vacuum Filtration 18
3.2.6.1 VF35 Vacuum Filtration Unit 19
3.2.6.2 VF25 Vacuum Filtration Unit 19
3.2.6.3 VF10 Vacuum Filtration Unit 19
3.3 UNDERSTENCIL CLEANER CYCLE 20
3.4 ELECTRICAL SCHEMATIC 21
3.5 PNEUMATIC SCHEMATIC 24
3.6 REPLENISHMENT PROCEDURES 25
3.6.1 Fabric Roll 25
3.6.1.1 Fabric Roll Removal 25
3.6.1.2 Fabric Roll Replacement 27
3.6.2 Solvent 29
3.7 REPLACEMENT PROCEDURES 31
3.7.1 Plenum Chamber Insert 31
3.7.1.1 Plenum Chamber Insert Removal 31
3.7.1.2 Plenum Chamber Insert Replacement 32
3.7.2 Plenum Chamber 33
3.7.2.1 Plenum Chamber Removal (Standard USC) 33
3.7.2.2 Plenum Chamber Replacement (Standard USC) 33
3.8 ADJUSTMENTS AND SETTINGS 34
3.8.1 Under Stencil Cleaner Home Position 35
3.8.2 Under Stencil Cleaner Parallelism And Magnet Positions 36
3.8.3 Under Stencil Cleaner Height 39
3.8.4 Lift Mechanism Air Flow Controller 45
3.9 CALIBRATIONS 47
3.9.1 External Solvent Tank 47
3.10 MAINTENANCE 48
3.11 TROUBLESHOOTING 49
3.11.1 Stencil Cleaner Blade Error (Optional Lift Sensors Fitted) 49
3.11.1.1 Recovery Process 49
1 MANUAL INFORMATION
1.1 MANUAL SCOPE
STANDALONE MANUAL TYPHOON UNDER STENCIL CLEANER 06/2020 5
1
MANUAL INFORMATION
1.1 MANUAL SCOPE
This manual is a complementary supplement to your machine’s documentation. It provides tech-
nical, operating and safety information with advice relevant to its subject. For information regarding
general and specific machine technical, operating and safety information, refer to the relevant
machine documentation.
1.2 MANUAL CHANGE REQUEST
Information in this manual is subject to change without notice.
No part of this manual may be reproduced, transmitted in any form or means, electronically or
mechanically, including photocopying and recording, for any purpose without the express written
permission of ASM Assembly Systems Singapore Pte Ltd.
Every effort has been made during the composition of this manual to ensure that the information
has been clearly presented and correct in all respects.
If during the use of this manual, errors or omissions are found, or the reader considers that im-
provements are necessary to overcome any ambiguity or inaccuracies, a copy of the manual
change request form (see overleaf) should be completed and either faxed or forwarded to the ad-
dress below, accompanied with a copy of the relevant page and/or figure of the manual with the re-
commendation.
Quality Manager
ASM Assembly Systems Weymouth Ltd
11 Albany Road
Granby Industrial Estate
Weymouth
Dorset
DT4 9TH
England
Tel: +44 1305 760760
Fax: +44 1305 760123
