3 TYPHOON UNDER STENCIL CLEANER

3.8 ADJUSTMENTS AND SETTINGS

46 STANDALONE MANUAL TYPHOON UNDER STENCIL CLEANER 06/2020

17. Select Run Diagnost multiple times ensuring that the lift mechanism raises and lowers fully

(without struggling or slowing).

18. Select Exit.

19. Select Exit.

20. Select Back.

21. Refit machine front panel removed at Step 1.

3 TYPHOON UNDER STENCIL CLEANER

3.9 CALIBRATIONS

STANDALONE MANUAL TYPHOON UNDER STENCIL CLEANER 06/2020 47

3.9 CALIBRATIONS

WARNING

RECOMMENDED SOLVENTS. ANY SOLVENTS USED MUST COMPLY WITH

LOCAL ENVIRONMENTAL GUIDELINES. ASM RECOMMEND USING

SOLVENTS THAT ARE ENVIRONMENTALLY FRIENDLY, IE CFC FREE AND

WATER BASED. SOLVENTS USED MUST HAVE FAST EVAPORATION RATES

AND FLASHPOINT SPECIFICATIONS GREATER THAN 39°C.

CAUTION

PRINT MEDIUM AND SOLVENTS. WHEN USING OR HANDLING ANY PRINT

MEDIUM OR SOLVENT FORMULATION THE MANUFACTURER’S SAFETY

DATA SHEETS MUST BE STRICTLY ADHERED TO.

MANDATORY

TOXIC SUBSTANCES MAY BE PRESENT. SAFETY GLOVES MUST BE WORN.

MANDATORY

TOXIC SUBSTANCES MAY BE PRESENT. EYE PROTECTION MUST BE WORN.

3.9.1 External Solvent Tank

To enable the machine software to calculate when solvent is low, the weight of an "empty" solvent

container and a full solvent container need to be measured by the external solvent tank's load cell.

NOTE

To prevent air locks being created in the solvent tubing during an USC cleaning cycle, it is import-

ant that the solvent tank is never completely empty of solvent. For the purposes of this procedure

the "empty" solvent tank should contain a level of solvent that just covers the filter at the end of the

solvent tubing.

To calibrate the software carry out the following procedure:

1. Ensure that the external solvent tank is fitted with an "empty" 5 litre container.

2. Select Maintenance.

3. Select Calibrations.

4. Select Classic Calibrations.

5. Select Solvent.

6. Select Set Solv Empty.

7. Confirm by selecting Yes.

8. Replace the "empty" 5 litre container with a full 5 litre container of solvent to be used.

9. Select Set Solv Full and confirm by selecting Yes.

10. Select Exit.

11. Select Exit.

12. Select Back.

NOTE

Due to solvents having different densities, this calibration must be performed when changing

solvents.

3 TYPHOON UNDER STENCIL CLEANER

3.10 MAINTENANCE

48 STANDALONE MANUAL TYPHOON UNDER STENCIL CLEANER 06/2020

3.10 MAINTENANCE

The following table and accompanying illustrations details the monthly maintenance for the USC.

Typhoon Under Stencil Cleaner Tick

Remove any debris and clean the linear bearings.

Remove any debris and clean the magnet assemblies.

Check the condition of the squeegee blades (Poly Blade Insert Option Only).

Squeegee blades must be replaced every 6 months.

Check the condition of all hoses and connections.

Check the condition and security of all earthing looms.

Using 0.35mm cleaning tool (ASM Part 03228698-01 - purchasable option), check and

clear the solvent spray holes of any blockage/build-up.

Check external solvent tank for leaked solvent, drain into suitable solvent container.

Check the oscillating motor moves the cleaner mechanism back and forth (Option).

Check that the fabric feed mechanism operates correctly.

Check that the fabric roll clamp operates correctly.

Check that the cleaner mechanism raises and lowers smoothly.

Check the stencil cleaner height.

Check that solvent dispenses evenly across the fabric and it is at a suitable pressure.

Check the operation of the vacuum filtration unit.

Perform a USC cycle and confirm correct operation.

1 Home Magnets 3 Camera Beam

Attachment Magnets

2 Linear Bearing Blocks 4 Solvent Spray Holes
