Appendix
chapter 6
Advanced Chip Shooter
DECAN S2 Maintenance Handbook
6-1
Consumable Parts List
chapter 6
Appendix
No PART NAME PART No. Replacement cycle REMARK
1 FUSE[250V 5A] EP10-900438
Replacement due to failure Refer to the Replacement of a Fuse.
2 FUSE[250V 10A EP10-900439
3 FILTER-ELEMENT[PF3-24-005-01] HP04-000103A
"Replacement due to contamination found
during daily inspection
(Max. recommended replacement cycle: 1
year)"
Refer to the inspection and replace the Air Filter
4 FILTER-ELEMENT(0.3)[PFH3000-005A-608] HP04-000104A
"Replacement due to contamination found
during daily inspection
(Max. recommended replacement cycle: 1
year)"
Refer to the inspection and replace the Mist
Separator Filter
CLEANING KIT AM03-900053 When consumed up Cleaning Kit for Maintenance
6 BELT-SHUTTLE_MAM;FLAT,945,6W,1.2MM MC05-000068A
"Replacement due to abnormalities found
during monthly visual inspection
(Max. recommended replacement cycle: 6
months)"
Conveyor belt
7 BELT-MAM-5P-1504-6W;FLAT,1504,6,1.2 MC05-000234
8 BELT-MAM-5P-1760-7W;MAM-5P,1760,7,1.2 MC05-000261
9 FLAT_BELT_WORK_MOVE_750 MAM-5P MC05-900130
10 BELT-MAM-5P-860-7W;MAM-5P,860,7,1.2 MC05-000254
11 CONV_WORK_BELT_2 MAM-5P-1065-7W TE07-900010
Consumable Parts List
Appendix
chapter 6
Advanced Chip Shooter
DECAN S2 Maintenance Handbook
6-2
Consumable Parts List
Appendix
No PART NAME PART No. Replacement cycle REMARK
12 SUCTION_FILTER VYF44-M-50M HP04-900036
"Replacement due to contamination found
during weekly inspection
(Max. recommended replacement cycle: 6
months)"
Refer to the inspection and replace the Head
Vacuum Filter
13 VALVE,SOLENOID-SOLENOID_VALVE HP14-000173
"Replacement due to contamination found
during weekly inspection
(Max. recommended replacement cycle: 2
year)"
Refer to the inspection the Solenoid Valve
14 NOZZLE_CN400_ASSY J90551072A J90551072A
Replacement due to failure Nozzle15 NOZZLE CN040 ASSY[J9055134C] J9055134C
16 NOZZLE CN065 ASSY[J9055136C] J9055136C
