Introduction Staff Qualifications and Training 1.3.6 SIPLACE on the World Wid e Web (WWW) 12 Assembly Instructions SIPLACE E 1.3.6 1 . 3 . 6 S I P L A C E o n t h e W o r ld W id e W e b ( W W W ) SIPLACE on the Wor ld W…

Introduction

1.3.4 Validity of Document Other Instructions

Assembly Instructions SIPLACE E 11

Always place the modules on a conductive surface (table with an ESD coating, conductive ESD foam,

ESD bag or container).

Do not bring modules near visual display units, monitors or televisions. Keep them at least 10 cm away

from the screen.

1.3.3.4

1.3.3.4 Measurements and Modifications to ESD Modules

Measurements and Modifications to ESD Modules

Measurements of the assemblies may only be taken if

▪ The measuring device has been grounded (e.g. via protective conductor) or

▪ The measuring head of the potential-free measuring device has been briefly discharged before

measurement (e.g. touching blank metal control unit housing).

► Always use an earthed soldering iron if you carry out any soldering work.

1.3.3.5

1.3.3.5 Dispatching ESD Modules

Dispatching ESD Modules

► Always store modules and components in conductive packaging (e.g. metallized plastic bags or met

al sleeves) and dispatch them in conductive packaging.

► If the packaging is not conductive, place the modules in a conductive envelope before packaging.

Use conductive foam rubber, ESD bags, domestic aluminum foil or paper, for example. NEVER use

plastic bags or film.

► If the module has integral batteries, ensure that the conductive packaging does not touch or short-

circuit the battery terminals and, if necessary, first cover the terminals with insulating tape or mate

rial.

1.3.4

1.3.4 Validity of Document

Validity of Document

This document contains service work instructions for all SIPLACE E machines.

The service work described in this manual is divided into modules and is largely identical for all machine

types:

▪ If the work required for specific machines should differ from the standard procedure, this will be in

dicated with reference to the machine number, series and delivery state.

▪ Diagrams should be seen as examples e.g. a machine with different paint finish does not mean that

the following information only applies to the machine type shown.

The main focus of this manual is on a description of mechanical service work.

Please refer to the circuit diagram folder for any electrical checks.

1.3.5

1.3.5 Release History

Release History

Release Changes

02/2015 Initial release

Introduction

Staff Qualifications and Training 1.3.6 SIPLACE on the World Wide Web (WWW)

12 Assembly Instructions SIPLACE E

1.3.6

1.3.6 SIPLACE on the World Wide Web (WWW)

SIPLACE on the World Wide Web (WWW)

Log into our SIPLACE

homepage at http://www.e-by-siplace.com.

► You can choose between the German and English versions.

The different sections contain information about our products, services and contact persons.

In addition, registered customers can also access the

SIPLACE User Group

. Here you can call up spe

cial information about our placement systems e.g.

▪ Technical documentation,

▪ Technical information,

▪ Spare parts lists etc.

Registration for the user group is very simple:

► Click on the Register link.

► Fill in the registration form and send it off to us.

Soon afterwards, you will receive your access authorization with USER ID and password.

1.4

1.4 Staff Qualifications and Training

Staff Qualifications and Training

Qualified or adequately trained personnel means that these people are familiar with the setting up, op

eration and maintenance of automatic placement systems and add-on devices and are suitably qualified,

e.g.:

▪ Have been trained, instructed or authorized to switch on and off, isolate, earth and identify electrical

circuits and system components in accordance with normal safety standards.

▪ Have been trained or instructed in the upkeep and use of appropriate safety equipment in accord

ance with normal safety standards.

▪ Have received first aid training.

Brief Description

Scope of Delivery

Assembly Instructions SIPLACE E 13

2 Brief Description

Brief Description

With the power conversion kit [03102858-xx] you can adapt the power supply units on SIPLACE® E

placement machines to the supply networks in individual countries.

2.1

2.1 Scope of Delivery

Scope of Delivery

Power conversion kit for 3 x 200 V – 240 V [03102858-xx]

The conversion kit consists of the following parts:

2.2

2.2 Tools and Equipment

Tools and Equipment

▪ Set of DIN 911 Allen keys

▪ Set of slotted-head screwdrivers

▪Multimeter

▪ Spanner

Quantity Item number Product name

1 03107593-xx 3UI 120-51 (autotransf. vert.)

1 03101687-xx Cable, PSU, main breaker

1 03102898-xx US power supply, supply bracket (E series)

1 03111406-xx Option - transformer cover

1 03111414-xx Cable, PE for E-Series transformer cover

2 03042559-xx ISO 4762 - M 5 x 8-A2-70

2 03047704-xx Serrated lock washer M5-FST,1.4401

2 03047655-xx Contact disc -5-FSt-flZnnc-480h

1 03008203-xx ISO 4035 - M 5-A2-035

2 03042583-xx ISO 4762 - M 8 x 12-A2-70

2 03066813-xx ISO 7092 - 8 - 200 HV - A2

4 03042553-xx ISO 4762 - M 4 x 12-A2-70

4 03066810-xx ISO 7092 - 4 - 200 HV - A2

4 03046903-xx Lens flange screw M4x6-A2-70

1 03009345-xx Warning label no. 206
