Item no. 00197485-04 Edition 11/2018
Checklist: Head Exchange Kit
www.asm-smt.com
* From SW 711.1 “calibration tool SST48/49 (T100)” replaces “calibration jig version SST23 (T04)” for all cameras
** Nozzle type 4335/6335 is required for the calibration of camera type SST49 only
03109694-xx - Head Exchange Kit for CPx
C08
00308458-xx
Cable ties B=2.5mm, L=102mm Panduit
20
T07
03078400-xx
Torque screwdriver ESD 1,0-5,0 Nm
1
T08
03078706-xx
Bitholder f. screwdriver TorqueVario
1
T09
03073256-xx
Bit extension 170 TX20
1
T12
00320265-xx
Allan key set 0,7-2mm
1
T15
03080081-xx
Torx allan key TX8
1
T19
00318673-xx
Side cutter electronic size 110
1
T47
00386253-xx
Torque screwdriver ESD 0,4-1,0 Nm
1
T50
none
Tool to adjust torque screwdriver
1
T100
03157023-xx
Calibration tool SST48/49*
-
00197485-xx
Checklist head exchange kit
1
-
03107880-xx
case w. inlay Head Exchange Kit
1
03109567-xx - Head Exchange Kit option for CP20A
T17
03015222-xx
Nozzle type 1235, cpl.
48
T51
03078596-xx
Protective tubing BE-sensor CP20
1
T83
03016831Sxx
Magazine complete
4
03114808-xx - Head Exchange Kit option for CP20P
T60
03098748-xx
Pipette Typ 4235 kpl. TPU
40
T62
03112729-xx
Abdeckung BE-Sensor CP20P
1
T63
03101503-xx
Nozzle magazine Typ 40xx
2
03109570-xx - Head Exchange Kit option for CPP
T05
03010565-xx
Calibration part version 3
2
T14
03080984-xx
BE-sensor protective cover / CPP
1
T16
03070280-xx
Nozzle type 2057 cpl. / TPU
24
T84
03066107-xx
Nozzle magacine type 20xx
2
03114808-xx - Head Exchange Kit option for CP20P2
T63
03101503-xx
Nozzle magazine Typ 40xx
2
T95
03156306-xx
Protection cover CO sensor CP20 P2
2
W59
03145384-xx
Nozzle type 4335/6335 kpl. TPU**
40
Space for old calibration tool
T04
03034148-xx
Calibration jig, version SST23*
2
