2.3 Overview main components
Technical Training E by DEK 12/2017 13
Camera Module
The camera system contains the following
camera:
●
Hawkeye 750
Conveyer System
Standard is single Conveyor Fixed rail outer.
Screen Mount
The Screen Mount is the receptacle for the
stencil during printing operations.
Different versions are available.
Other hardware options
Board Support Tooling Basic manual plate options for:
●
Support tooling
●
Vacuum tooling
●
Grid-Lok Tooling
●
Support pillars
Roll Height Monitor To check and control the paste height
Stinger Stinger is a glue dot dispenser module attached to the camera
carriage
See the machine technical reference manual for a full list of options and further details.
