4 Conveyor System
4.7 Maintenance
28 Technical Training E by DEK 12/2017
Problems Solution
Board remains jammed (time overflow)
●
Check the board width in the product
●
Check belt support after running in
●
Check parallelism of the rails
Board / belt jumps from the rail
●
Belt testing (stretching)
●
Check belt speeds
●
Check pulleys
●
Distance belt support (0.3-0.35mm check)
4.7 Maintenance
Maintenance tasks (For detailed instructions refer to the technical reference manual).
Maintenance content Interval Requirement
Ensure table surface is free from contamination daily IPA Wipes
Ensure vane does not foul the sensor 6 monthly -
Check belt condition 6 monthly -
Ensure all cabling is free and not trapped by table movement 6 monthly -
