Page
SAMSUNG TECHWIN
18
SM411
Conveyor Ass'y
NO. LEVEL PART NO. PART NAME Q'TY TYPE Old No. Stock Apply Reference
27 J7153036A SLIDE GUIDE 2
28 J7153373A FIDUCIAL DISK[J7153373A] 12
29 J7253008A STOPPER 8
30 J7253009B STOPPER 2 [J7253009B] 8
31 J71531010B LM_BASE 2
32 J66071087A LM_GUIDE_WORK 2 J66071015A
J66071088A LM_GUIDE_SHUTTLE 2
33 J70531017B PCB_GUIDE_FC J70531017A 2
34 J70531016B PCB_GUIDE_RC J70531016A 2
35 J71531007A PULLEY_WIDTH_MOTOR J71531007A 2
36 J70531015A STOPPER_BRACKET_WORK J70531015A 2
37 J70531050A STOPPER_TOP_PLATE J70531050A 2
38 J70531029B STOPPER_POST 2 J70531029A
39 J71531006A SUPPORT_BRACKET_L J71531006A 2
40 J71531005A SUPPORT_BRACKET_S J71531005A 2
41 J70531014B SUPPORT_FIX_RAIL_LEFT 2 J70531014A
42 J70531013A SUPPORT_FIX_RAIL_RIGHT J70531013A 2
43 J70531012C SUPPORT_MOVE_RAIL_TL 2 J70531012B
44 J70531011A SUPPORT_MOVE_RAIL_TR J70531011A 2
45 J70531028A TENSION_BEARING_PIN J70531028A 4
46 J70531027A TENSION_BRACKET J70531027A 4
47 J66021007A TIMMING_BELT_WIDTH 180-3GT-9 2
48 J71531008A PULLEY_W_MOTOR J71531008A 2
49 J71531024A WIDTH_PULLEY J71531024A 2
50 J70531066A WORK_WIDTH_SENSOR_DOG J70531066A 2
51 J66021006A BELT_WORK MAM-5P-1550-6W 4
52 J71531013B WORK_FRONT_FRAME J71531013A 2
Page
SAMSUNG TECHWIN
19
SM411
Conveyor Ass'y
NO. LEVEL PART NO. PART NAME Q'TY TYPE Old No. Stock Apply Reference
53 J71531004B WORK_REAR_FRAME J71531004A 2
54 J65041004A CABLE_VEYOR HSP0130-1B-18R-28LINK 2
55 J6073010136H C-RING DIA11(HOLE) 8 J6073000036H
56 J72531005B DUMP_BOX 2
57 J70531059A DUMP_BOX_SUPPORT J70531059A 2
58 J70531103A CV_SUPPORT_M_RAIL J70531103A 2
59 J1300517 C-RING [10mm (SHAFT)] 1
60 J66011019A BEARING 6908ZZ 2
61 J66071087A LM_GUIDE_WORK 2 J66011020A
J66071088A LM_GUIDE_SHUTTLE 2
62 J6601134A BEARING[694ZZ] 2
63 J66021008A BELT_SHUTTLE_1650 MAM-5P-1169-6W 2
64 J66021009A TIMMING_BELT_SW 327-3GT-12 2
65 J66021010A TIMMING_BELT_SM 444-3GT-12 1
66 J66061005A CYLINDER AQ2A12-30D 1
67 J6619031A SUPPORT UNIT[FK-10] 1
68 J1300121 ELBOW FITTING [M-5HLH-4] 1
69 J6711156A HOSE NIPPLE [M-5H-4](D/C?) 1
70 J70531030A SUPPORT_ST_MOTOR J70531030A 1
71 J70531031A SM_HOME_SENSOR_DOG J70531031A 1
72 J70531032A ST_SENSOR_BRACKET_2 J70531032A 1
73 J70531033A ST_SENSOR_BRACKET_1 J70531033A 1
74 J70531036A NUT_HOUSING J70531036A 1
75 J70531037A MOTOR-BRACKET-SHUTTLE J70531037A 1
76 J70531038A MOTOR_BRACKET J70531038A 2
77 J66191024A IDLER_ASSY_110 A-3_11.0 8 J70531039A
78 J70531043A BRACKET_SHUTTLE_STP J70531043A 1
Page
SAMSUNG TECHWIN
20
SM411
Conveyor Ass'y
NO. LEVEL PART NO. PART NAME Q'TY TYPE Old No. Stock Apply Reference
79 J70531044A WD_NUT_BEARING_STOPPER J70531044A 1
80 J70531045A W_TENSION_TUBE J70531045A 1
81 J70531047A W_TENSION_SCREW J70531047A 1
82 J70531048A W_TENSION_PLATE J70531048A 1
83 J70531055A SM_R_DOG J70531055A 1
84 J70531071A CNT_COVER J70531071A 2
85 J70531072B CNT_PANEL_FRONT J70531072A 1 J70531072A
86 J70531073B CNT_PANEL_REAR J70531073A 1 J70531073A
87 J71531015A SUPPORT_UNIT_ST_TAIL J71531015A 1
88 J71531016A PULLEY_SHUTTLE_WIDTH J71531016A 1
89 J71531017A PULLEY_S_W_NUT J71531017A 1
90 J71531018A ENTRY_PCB_GUIDE_1650 J71531018A 2
91 J71531020A ENTRY_FRAME_00_1650 J71531020A 1
92 J71531019A ENTRY_FRAME_01_1650 J71531019A 1
93 J71531021B BLOCK_SHUTTLE_REAR_LEFT 1
94 J71531022A BLOCK_SHUTTLE_FRONT J71531022A 1
95 J71531025A PULLEY_SHUTTLE_MOTOR J71531025A 1
96 J72531003A SM_S_BUMPER J72531003A 1
97 J72531006A SM_M_BUMPER J72531006A 1
98 J72531004A SM_WR_BUMPER J72531004A 2
99 J70531062A SUPPORT_ST_MOTOR_2 J70531062A 1
100 J70531076B BRACKET_BD_OUT_SENSOR 1 J70531076A
101 J31081005A SERVO_MOTOR_PB PBM565DXC26 1
102 J31081004A SERVO_MOTOR_PB PBM423DXC24 1
103 J31041014A STEP_MOTOR 2S56Q-01842SR2 1
104 J65041002B CABLE_VEYOR HSP0180_2B_28R_21LINK 2 J65041002A
105 J32111003A PHOTOELECTRIC_SENSOR 5
