Page SAMSUNG TECHWIN 76 SM411 C able Ass’y (2/2) 3 4 3 3 3 5 F. R R.L 3 3 3 3 4 5 2 2
Page
SAMSUNG TECHWIN
75
SM411
Cable Ass’y (1/2)
Solenoid Valve
U2-4-8*5U2-4-8*5
J6702021A J6702021A
K180-4E1-21-DC24VK180-4E1-21-DC24V
J6711157AJ6711157A
KQ2L08-01SKQ2L08-01S
3-J6712008A3-J6712008A
PT 1/8PT 1/8
U2-4-8*5U2-4-8*5
J6711140AJ6711140A
SS8-1/8SS8-1/8
HARNESS ASSYHARNESS ASSY
J9080795A MAIN AIR SOL PWR CABLE ASSYJ9080795A MAIN AIR SOL PWR CABLE ASSY
1
Page
SAMSUNG TECHWIN
76
SM411
Cable Ass’y (2/2)
3
4
3
3
3
5
F. R
R.L
3
3
3 3
4
5
2
2
Page
SAMSUNG TECHWIN
77
SM411
Cable Ass’y
NO. LEVEL PART NO. PART NAME Q'TY TYPE Old No. Stock Apply Reference
A-1 J91671120A SM411_CABLE_ASSY J91671120A 1
1 J6702021A SOLENOID VALVE [K180-4E1-21-DC24V] 1
3 J3105010A COOLING FAN[4715MS-22T-B50] 4
4 J32110015B Photoelectric Switch 2
5 J70541103A FRONT_SENSOR_BKT2 J70541103A 2
6 J70541102A FRONT_SENSOR_BKT1 J70541102A 2
7 J90831155C FY_AXIS_SENSOR_CABLE_ASSY 1 J90831155B [129] at 93 page
8 J90831156D RY_AXIS_SENSOR_CABLE_ASSY SM33-AX004 1 J90831156B [130] at 93 page
9 J90831026B .ASTER_CPU1-FFDR_CAN_CABLE_ASSY SM33-CA0 1 J90831026A [131] at 83 page
10 J90831027C FFDR-CVIF_CAN_CABLE_ASSY SM33-CA002 1 J90831027A [132] at 83 page
11 J90831028C MASTER_CPU2-RFDR_CAN_CABLE_ASSY SM33-CA0 1 J90831028A [133] at 84, 85 page
12 J90831029D CVIF-FRONT_FLAT_CAN_CABLE_ASSY 1 J90831029B [134] at 85 page
13 J90831030C RFDR-REAR_FLAT_CAN_CABLE_ASSY SM33-CA005 1 J90831030A [135] at 84 page
14 J90831285A FDR_UNLOCK_LEFT_CABLE_ASSY SM33-CS034-1 1 [136] at 94 page
15 J90831286C FDR_UNLOCK_RIGHT_CABLE_ASSY 1 [137] at 94 page
16 J90831287D FEEDER_UNLOCK_SENSOR_CABLE_ASSY 1 J90831287B [138] at 94 page
17 J90831288A AXIS_SENSOR_BD_DATA_CABLE_ASSY SM33-CS03 1 [139] at 82, 86, 93, 94 page
18 J90831289C AXIS_SENSOR_BD_STP-BUT_CABLE 1 J90831289B [140] at 82, 86, 93 page
19 J90831290B CONVEYOR_LEFT_IF_BD_CABLE_ASSY 1 [141] at 93 page
20 J90831291B CONVEYOR_RIGHT_IF_BD_CABLE_ASSY SM33-CS0 1 J90831291A [142] at 93 page
21 J90831131B CONV_SW_OUTPUT_CABLE_ASSY SM33-CV003 1 J90831131A [143] at 85 page
22 J90831132C TOWER_LAMP_EXT_CABLE_ASSY 1 J90831132B [144] at 86 page
23 J90831136B CONV_SW_INPUT1_CABLE_ASSY SM33-CV013 1 J90831136A [145] at 87 page
24 J90831137B CONV_SW_INPUT2_CABLE_ASSY SM33-CV014 1 J90831137A [146] at 87 page
25 J90831144C SERIAL_COMM_CABLE_ASSY 1 J90831144B [147] at 88 page
26 J90831258B KVMS-CONV_IF_BD_CABLE_ASSY SM33-CV023-1 1 J90831258A [148] at 88, 104 page
27 J90831259C KVMS-FRONT_TEACHING_BOX_CABLE 1 J90831259B [149] at 104 page
