Page HANWHA TECHWIN 205 SM471 Articles of Consumption NO. Lev . PA R T N O . P ART NAME Q'TY Old No. Supply Reference 1 EP10-900 438 FUSE[2 50V 5A] 2 EP10-900 439 FUSE[2 50V 10A] 3 HP04-900036 SUCTION FIL TER [VYF44…
Page
HANWHA TECHWIN
204
SM471
Articles of Consumption
Page
HANWHA TECHWIN
205
SM471
Articles of Consumption
NO. Lev. PART NO. PART NAME Q'TY Old No. Supply Reference
1 EP10-900438 FUSE[250V 5A]
2 EP10-900439 FUSE[250V 10A]
3 HP04-900036 SUCTION FILTER [VYF44-M-50M]
4 HP04-900020 FILTER ELEMENT[AF40P-060S]
5 HP04-900031 FILTER_ELEMENT AFM40P-060AS
6 HP14-000173 VACUUM PUMP FILTER
7 MC05-900057 BELT WORK MAM-5P-1550-6W Inspect and replace (6 months)
8 MC05-900059 BELT SHUTTLE 1650 MAM-5P-1169-6W Inspect and replace (6 months)
9 HP14-900021 SOLENOID VALVE VA01PEP34A-1U-F HP14-900037 2 Years
10 HP14-900038 SOLENOID VALVE[RCS242-M3-D24NP] 2 Years
11 J9055134C CN040 NOZZLE ASSY
12 J9055136C CN065 NOZZLE ASSY
13 J90551072A CN400 NOZZLE ASSY
14 HP09-000258 GREASE GUN (only for 70g)
15 CM01-900473 TRI-FLOW [59ML] GREASE (NOZZLE)
16 CM02-000059 GREASE SPINDLE, MIRROR CAM, CONV LM GUDIE
17 CM02-000083 GREASE 70g X,Y FRAME LM GUIDE, X,Y BALL SCREW
18 CM02-000084 GREASE 400g X,Y FRAME LM GUIDE, X,Y BALL SCREW
19 CM02-000092 GREASE CONV LEAD SCREW
20 AM03-900053 CLEANING KIT
21 J7500003B BACK UP PIN
Page
HANWHA TECHWIN
206
SM471
