Maintenance • Preventive Maintenance
5—2 PS288 Owner’s Manual
The information in this section is organized as follows:
• Interval Table on page 5-2
• Materials on page 5-3
• Procedures Performed Every Day on page 5-4
• Procedures Performed Every Week on page 5-4
• Procedures Performed Every Month on page 5-5
• Procedures Performed Every Three Months on page 5-12
• Procedures Performed Every Six Months on page 5-15
• Procedures Performed Once a Year on page 5-23
Interval Table
The recommended intervals in the table below are based on the system pro-
cessing 100,000 devices per month. Information about these procedures and
intervals can be found on the pages referenced in the Page column.
Interval Component Action Page
Every
Day
Sockets Clean with dry compressed air. Check for wear;
replace if necessary.
5-4
Input air pressure Verify input air pressure is 620-827 kiloPascals
(90-120 PSI).
1-2
Every
Week
General system Clean tops of modules, especially the clamp area, and
all areas in work envelope with a clean brush or dry
compressed air.
5-4
Vision camera lens Clean with dry compressed air, lens cleaning tissue,
and isopropyl alcohol.
5-4
Device probe tip on PNP head, on
tape output PNP head (if installed),
and on shuttle pedestals (if
installed)
Clean and inspect tips to make certain they can create
a good vacuum seal on the device. Replace if probe
tip is worn, cut, or damaged.
5-4
Automatic tray feeder (if installed) Check feeder and conveyor belts. Clean; replace if
necessary.
5-5
Every
Month
Input air filter Check; clean and replace if necessary. Drain excess
fluid.
5-5
Shuttle assembly Clean shuttle assembly. 5-5
Shuttle assembly Adjust tension on shuttle belt. 5-6
Laser housing Clean housing to remove laser marking dust. 5-7
Laser marker fume extractor Replace the pre-filter if marking regularly. 5-8
Laser marker shuttle assembly Clean. 5-9
PNP head vacuum filter and silencer Check; replace if necessary. 5-11
Automatic tray feeder (if installed) Clean system. Check pinch roller; replace if
necessary.
5-12
Maintenance • Preventive Maintenance
PS288 Owner’s Manual 5—3
Materials
To perform preventive maintenance procedures on the PS288, you need the
following materials:
• Grease gun (THK MG70 with AFB grease or equivalent)
• Lens cleaning paper
• Isopropyl alcohol
• Antistatic cleaner
• Silicone lubrication spray
• Tri-Flow lubricant (Data I/O part number
560-3300-901)
• Dry compressed air
• Safety goggles
• Disposable protective gloves
• SAE and metric hex head wrenches and Allen wrenches
• Shop vacuum cleaner
• Diagnostic adapter board
WARNING: Always wear protective eye goggles when you clean
with pressurized air. Pressurized air blown directly on the eye or
debris blown into the eyes could cause permanent eye damage.
Every
3 months
Shuttle belt Replace if worn; adjust if loose. 5-12
PNP head motor amps Check connections; tighten if necessary. 5-12
Gantry servo motor amps Check connections; tighten if necessary. 5-13
Gantry mounting bolts Check; tighten if necessary. 5-14
Tray-present sensors Check; tighten and reset if necessary. 5-15
Every
6 months
PNP head and PNP gantry wiring
harnesses
Check; tighten if necessary. 5-15
Flexible cables Clean and check; tighten if necessary. 5-16
Vision camera Check mounting bolts; tighten if necessary. 5-18
Laser marker fume extractor Replace the pre-filter and pleated filter if marking
regularly.
5-18
Laser Computer Replace Laser Computer air filter. 5-22
Once a
Ye ar
Gantry lead screws Once a year, or whenever the gantries become
noisier, clean and lubricate
.
5-23
Laser marker fume extractor Replace all filters. 5-24
FlashCORE programmers
Calibrate voltages within the FlashCORE
programmers.
5-27
Interval Component Action Page
Maintenance • Preventive Maintenance
5—4 PS288 Owner’s Manual
Procedures Performed Every Day
Clean and Check the Sockets on the Socket Module
1. Use clean, dry compressed air to remove dirt from the sockets.
2. Check the sockets for wear and replace if necessary.
NOTE: The socket replacement cycle depends upon the type of
socket used and the socket manufacturer. For the most current
replacement guidelines, refer to the documentation shipped with
your sockets.
Procedures Performed Every Week
Clean the General System
General cleaning should be performed on a weekly basis. General cleaning
includes but is not limited to the following:
1. Remove all dropped devices, debris, and other manufacturing materials
from all working areas.
2. Remove all devices and manufacturing materials that may have fallen
inside the system.
3. Use dry compressed air to remove all dust and debris from the table
surface, under the machine, and from all other visible areas.
4. Dust the safety shields, inside and outside, with an antistatic cleaner.
5. Wipe the top and side skins to remove grease, fingerprints, and dust.
6. Dust the top surfaces of the input/output modules.
Clean the Vision Camera Lens
1. Dry compressed air—
Use dry compressed air to remove all dust and other foreign material
from the camera lens.
2. Lens cleaning tissue—
Clean the lens using a lens cleaning tissue dampened with isopropyl
alcohol if required.
Check the Device Probe Tips
A worn or damaged probe tip on the PNP head or the tape output PNP head
(if installed) will cause dropped devices and placement problems.
1. Check device probe tip—
1a) Check the device probe tip for cracks or tears in the rubber.
1b) If necessary, replace with a probe tip of the same size.
2. Verify vacuum on new probe tip—
2a) From the Setup window, click System.
2b) Click Gantry to open the Gantry window.
2c) Click the Vacuum switch to ON.
2d) Place a device on the probe tip.
2e) If the vacuum does not firmly hold the device, replace the probe tip
with a probe tip of the same size.
