Appendix A
A-2 PS288 Owner’s Manual
Appendix A
PS288 Owner’s Manual A-3
ON = LED turned On (i.e. lit green) - indicates logical bit value of 0 (zero).
Input Ports - Sensor signals coming into the I/O Controller (as sensed by I/O Controller)
Port-1
Bit-0 PNP Head Vacuum Sensor. ON = sensed device on pickup tip.
Bit-1 Socket Opener - UP. ON = Socket Opener is in the UP position
Bit-2 Socket Opener - down. ON = Socket Opener down, socket is pressed open.
Bit-3 Tray #1 Present. ON = Tray-1 Present - OR Tray Feeder #1 READY
Bit-4 Tray #2 Present. ON = Tray-2 Present - OR Tray Feeder #2 READY
Bit-5 Tray #3 Present. ON = Tray-3 Present
Bit-6 Safety Shield/Door Interlocks. ON = Doors Closed, OFF = Door Open. Machine will NOT run.
Bit-7 Not Used
Port-2
Bit-0 ON = Auto Tray Feeder #1 ERROR-1
Bit-1 ON = Auto Tray Feeder #1 ERROR-2
Bit-2 ON = Auto Tray Feeder #2 ERROR-1
Bit-3 ON = Auto Tray Feeder #2 ERROR-2
Bit-4 Not Used
Bit-5 ON = Device present on Cup#2, Laser Vacuum Sensor -SV14, Cup#2 on Laser Transfer Shuttle.
Bit-6 Labeler Sensor
Bit-7 ON = Device present on Cup#1, Laser Vacuum Sensor -SV12, Cup#1 on Laser Transfer Shuttle.
Port-3
Bit-0 ON = Input Shutter Piston, Open - Shutter should NOT be covering Laser Bay
Bit-1 ON = Input Shutter Piston, Closed - Shutter should be covering Laser Bay
Bit-2 Label Sensor - Limited Use, only on some units
Bit-3 Ink Marker Door Closed - Limited Use, only on some units
Bit-4 Labeler (Apollo) Finished Marking. 0 = On Not Ready, 1 = Off = Ready for Marking
Bit-5 ON = Output Shutter @ Tape Out Unit Closed
Bit-6 ON = Output Tape Ready. (V-Tek) Taping unit Ready
Bit-7 ON = Output Tape Error, could be due to one of the 5 sensors on the Tape-Out Unit
Port-4
Bit-0 ON = Input Shutter Closed - Door Sensor. Door Closed and sensed by Opto Sensor on side.
Bit-1 Air Flow Sensor for FUMEX filter. ON indicates insufficient air flow -> Replace Filter(s)
Bit-2 Laser System Ready. ON indicates Device under Laser Head and ready to be marked
Bit-3 Not Used
Bit-4 Not Used
Bit-5 Not Used
Bit-6 Not Used
Bit-7 Laser Done Marking. O =On, Laser has finished marking the device. Device ready to proceed.
I/O Controller LED Status - by Port Number
I/O Controller LED Status: Input Ports
Appendix A
A-4 PS288 Owner’s Manual
ON = LED turned On (i.e. lit green) - indicates logical bit value of 0 (zero)
.
I/O Controller LED Status - by Port Number
Output Ports - Si
g
nals
g
enerated by I/O Controller (commands from I/O Controller
)
Port-5
Bit-0 ON = Socket Opener Down command (via Solenoid 1SV1)
Bit-1 ON = Turn on Pickup Head Vacuum @ PnP (SMAC) head (via Solenoid 1SV2)
Bit-2 ON = Turn on Pickup Head Blow-off @ PnP (SMAC) head (via Solenoid 1SV3)
Bit-3 ON = Turn On Vacuum on shuttle pedestal, Cup-1 (Laser Vacuum - 2SV4)
Bit-4 ON = Turn On Vacuum on shuttle pedestal, Cup-2 (Laser Vacuum - 2SV2)
Bit-5 ON = Turn on Blow-off on shuttle pedestal, Cup-1 (via 2SV1)
Bit-6 ON = Turn on Circuit Breaker K1 (Main Contractor)
Bit-7 ON = Turn on Blow-off on shuttle pedestal, Cup-2 (via 2SV3)
Port-6
Bit-0 Synrad Laser Key
Bit-1 Tray Transfer Cylinder
Bit-2 Tray Position-1 Stop Cylinder
Bit-3 Auto Tray Feeder #1 INDEX command / si
g
nal
Bit-4 Auto Tray Feeder #2 INDEX command / si
g
nal
Bit-5 Tray Output Support Cylinder
Bit-6 Tray Output Singulate Cylinder
Bit-7 Part Ready at Tape-Out
Port-7
Bit-0 Output Shutter Piston @ Tape-Out Unit.
Bit-1 Inkmark Vacuum. O = On, Turn On Vacuum on shuttle pedestal
Bit-2 Inkmark Blow-Off. O = On, Turn on Blow-off on shuttle pedestal
Bit-3 ON = En
g
a
g
e Tray Clamps (via Solenoid 1SV7)
Bit-4 Laser Mark Command. ON = Mark the device Command to Synrad Laser System
Bit-5 Input Shutter Piston Command - 0 = On Close Shutter. Tied to Port-3 Bit-1
Bit-6 Label Apply Command - tied to "Applicator" button in AH400
Bit-7 ON = Advance Input Tape Feeder unit by one device
Port-9
Bit-0 Over Head Lamps - Gantry Light - Not Used
Bit-1 ON = Turn On Tube Feeder Vibratory Motor-1 (Input)
Bit-2 ON = Turn On Tube Feeder Vibratory Motor-2 (Output)
Bit-3 Tube Feeder Vibrator Motor-3 - Not Used
Bit-4 Vision Power - Not Used
Bit-5 Tube Feeder Vibrator Motor-4 - Not Used
I/O Controller LED Status: Output Ports
