43 cab - Produkttechnik GmbH / Tharo Systems, Inc. System Mode F AUL T-I RRECOVERABLE While switching on the printer or during printing, a fault has occured which cannot be cleared by the operator without cancelling the …
42 cab - Produkttechnik GmbH / Tharo Systems, Inc.
FF key Only if an applicator is installed :
Provides a label feed in order to synchronize the paper feed for
the next print run.
CAN key Cancels the current print job.
Switch into ONLINE mode.
(LED ONL on, LED CAN off, LED PSE off)
PSE key Continues current print job after error correction.
Switch into PRINT mode.
(LED ONL on, LED CAN off, LED PSE off)
System Mode FAULT-CORRECTABLE
The printer has encountered a fault during printing which is easily correctable
by the operator (e.g. "Out of paper"), following which the printing process may
be continued.
Display
The top line of the display shows alternately the type of fault and the total of the
remaining labels of the current print job.
LED Display
LED CAN on, LED PSE is flashing.
If an applicator is connected: LED FF is flashing.
Function Keys
Table 8 e Function keys in mode FAULT-CORRECTABLE
43cab - Produkttechnik GmbH / Tharo Systems, Inc.
System Mode FAULT-IRRECOVERABLE
While switching on the printer or during printing, a fault has occured which
cannot be cleared by the operator without cancelling the current print run. (e.g.
hardware fault)
Display
The display shows the type of fault.
LED Display
LED CAN is flashing.
Function Keys
CAN key Cancels the current print job.
Switch into ONLINE mode.
(LED ONL on, LED CAN off, LED PSE off)
If ONLINE mode cannot be entered, switch printer on and off
again.
If the fault remains contact Technical Service.
Table 8 f Function keys in mode FAULT - IRRECOVERABLE
44 cab - Produkttechnik GmbH / Tharo Systems, Inc.
System Mode SYSTEM TEST
When switched on, the Apollo automatically performs an internal self test.
If the test is completed successfully, the Apollo proceeds to the ONLINE mode,
or otherwise the printer switches to system mode FAULT - IRRECOVERABLE.
Display
The top line of the display shows the version of the printer, for instance
" **** APOLLO 3 **** ".
The bottom line of the display shows the numbers "123456" one after the other
depending on the progress of the several test steps.
LED Display
All LEDs flash up once briefly.
Function keys
The function keys have no effect.
