45cab - Produkttechnik GmbH / Tharo Systems, Inc.
System Mode SETUP
To enter the SETUP mode, use either one of the procedures described below :
either : press both keys, the key and the key
simultaneously when switching on the printer, and keep them
pressed down, until the system test is completed;
or : in ONLINE mode, press both keys, the key and the
key simultaneously for at least 5 seconds.
In SETUP mode, various printer parameters can be specified to suit the current
print requirements. (for details see Chapter 9)
Display
Following the completion of the system test, the display briefly shows "SET-
UP", followed by "Land" or "Country". Depending on the selection, all of the
setup parameters and their settings will be shown.
LED Display
All LEDs off.
Function Keys
ONL key Stores the chosen settings of the setup parameters and
completes the SETUP mode.
(i.e. switch into ONLINE mode/ LED ONL on)
FF key Skips to next setup parameter.
Reduces numerical setup values.
CAN key Skips to previous setup parameter.
Increases numerical setup values.
PSE key Confirms selected settings for parameters.
Table 8 g Function keys in SETUP mode
46 cab - Produkttechnik GmbH / Tharo Systems, Inc.
System Mode TEST PRINT
The TEST PRINT mode is entered by pressing the key when switching
on the printer, and keeping it pressed down until the system test is completed.
Following, an internal test sample will be printed. (for details see Chapter 10)
Then, the system test will be repeated.
Display
Following the completion of the system test, the display shows "Test print".
LED Display
LED ONL on.
Function Keys
CAN key Cancels the test print.
Switch into SYSTEMTEST mode.
Table 8 h Function keys in TEST PRINT mode
47cab - Produkttechnik GmbH / Tharo Systems, Inc.
System Mode MONITOR MODE/ ASCII Dump Mode
The monitor mode/ ASCII Dump mode is entered by pressing the key
when switching on the printer, and keeping it pressed down until the system
test is completed.
In this mode, the control codes received by the printer are directly printed as
text corresponding to the set font, rather than being interpreted as defined by
the programming.
Display
After the completion of the system test, the display shows "ASCII Dump
Mode".
LED Display
LED ONL on.
Function Keys
ONL key Switch into ONLINE mode.
FF key Initiates a paper feed of about .8 in (21 mm).
Table 8 i Function keys in MONITOR MODE/ ASCII Dump mode
