System Mode MONITOR MODE/ ASCII Dump Mode

The monitor mode/ ASCII Dump mode is entered by pressing the key

when switching on the printer, and keeping it pressed down until the system

test is completed.

In this mode, the control codes received by the printer are directly printed as

text corresponding to the set font, rather than being interpreted as defined by

the programming.

Display

After the completion of the system test, the display shows "ASCII Dump

Mode".

LED Display

LED ONL on.

Function Keys

ONL key Switch into ONLINE mode.

FF key Initiates a paper feed of about .8 in (21 mm).

Table 8 i Function keys in MONITOR MODE/ ASCII Dump mode

48 cab - Produkttechnik GmbH / Tharo Systems, Inc.

ONL key Switch into OFFLINE mode.

FF key For scrolling down within the file list stored on the card.

Reduces the quantity of labels to be printed.

CAN key For scrolling up within the file list of the card.

Increases the quantity of labels to be printed.

PSE key Confirms file selection.

Moves the cursor to the right when setting the quantity of labels

to print.

Switch into PRINT mode.

System Mode LABEL FROM CARD

Provided that a memory card is installed and a label format is present, in OFFLINE

mode, press the key to enter the LABEL FROM CARD mode.

In this mode, the labels stored on the card can be selected to print; for files

with a variable number of labels the quantity of labels to be printed can be set.

Display

The top line of the display shows "Label from card". The bottom line of the

display shows the file name of the first label file in the list stored on the card.

After the requested label has been selected, for files without a fixed number of

labels the display shows "No. of labels" in the top line and "00001" in the

bottom line.

LED Display

All LED's off.

Function keys

Table 8 k Function keys in the LABEL FROM CARD mode

49cab - Produkttechnik GmbH / Tharo Systems, Inc.

9 Setup

Using the setup mode, the configuration of the Apollo may be customized to

suit specific requirements. Initial setup should be performed when operating

the printer for the first time. Changes which become necessary to process

different print jobs, e.g. when different materials are used, can mostly be

accomplished by changing the software settings.

Start of Setup Mode

This mode is initiated by either simultaneously pressing the key and the

key when switching on the printer and keep them pressed down until the

system test is completed, or in ONLINE mode, press the same two keys down

for at least 5 seconds.

Starting the setup mode, the display shows "SETUP" for about one second ,

followed by "Land" or "Country" which represents the first of the parameters to

select from. Depending on the selection, the setup parameters and their

settings will be shown. The list of parameters is brought up in a row and may

be run through repeatedly.

Each time a parameter setting has been changed, there will be a request for

confirmation. There will not be a general request before leaving the setup

mode.

The setup mode can be left at any point by pressing the key.

The confirmed parameters will be saved.

If an already confirmed setting is not desired any more, switch off the printer

during the setup mode to cancel changes.

To return to the original factory default settings, press all three keys, the

key, the key, and the key simultaneously and keep them pressed

down until the display shows "--- RESTORE ---".

Note, that in some cases the printer may initially be set to certain parameters

which may differ from the default settings. (e.g. "Country")

On the following pages, you will find details to change the setting of the

parameters.
