Tear-off Position

If the "Tear-off position" is active, an additional feed forwards will take place

after completion of the print job. This makes it possible to cut off the last label

at the tear-off plate. After starting a new print job, first the label material will be

fed back until the front edge of the first label is located at the print line.

If the parameter is OFF, the label dispense stops immediately after the last

label has completely passed the print line.

Default Setting : Tear-off position OFF

Tear-off positio

xxx Ye s

Tear-off positio

xxx No

Selection

Confirmation

Fig. 9 s Set "Tear-off position" parameter

16 Debug mode

17 Tear-off positio

Pause reprint

Tear-off positio

Off

69cab - Produkttechnik GmbH / Tharo Systems, Inc.

70 cab - Produkttechnik GmbH / Tharo Systems, Inc.

10 Self Test / Test Print

Start of Test Print

To prepare a test print, load media (labels or continuous paper) which extends over

the entire print width of the Apollo.

If you want to perform the test print in thermal transfer mode, also use transfer

ribbon of the maximum width.

During test print, the Apollo will not sense any label gaps. The length of

the printout will be about 9 in (230 mm). Endless paper would suit best for

test prints, otherwise, a normal sheet of A4 paper which is cut to a width of

4.6 in (116 mm) can be used in thermal transfer mode.

To initiate a self test printout, press the key when switching on the printer

and keep it pressed down until the system test is completed.

The display shows "Test print", and the Apollo will print an internal test sample

which contains a variety of information about the configuration of the printer as

well as the results of the internal test.

The test printout can also include a range of hardware errors which have

occurred previously, even if they have disappeared again. This information is

important for service purposes and can only be deleted by Technical Support.

The information in the printout is also useful for checking the print quality, such

as differences in the blackness left/right, missing ink dots, etc. It is

recommended you carry out a print test immediately after receiving the printer.

After completing the test print, the Apollo will run the system test once again.

Then, the printer proceeds to ONLINE mode.

To cancel the test print press the key.
