73 cab - Produkttechnik GmbH / Tharo Systems, Inc. Err or c ode T ype of error HEX DEC 0001 1 dRAM fault 0002 2 dRAM multiplexer fault 0004 4 A/D converter fault 0008 8 Ribbon saver fault 0010 1 6 sRAM fault 0020 3 2 LCD…
72 cab - Produkttechnik GmbH / Tharo Systems, Inc.
1 Firmware Version
Type of device, part number, and date of the firmware version.
2 Setup and Status Information
Country : Setting of the "Country" parameter
Print mode : Setting of the "Transfer print" parameter
Label sensor : Setting of the "Label sensor" parameter
Interface : Setting of the "Interface" parameter
Cut Position : Setting of the "Cut position" parameter
Peel Position : Setting of the "Peel position" parameter
Printhead Pos. : Setting of the "Printhead position" parameter
Heat level : Setting of the "Heat level" parameter
Test result : Result of the system test. Any errors will be shown coded
as four digit hexadecimal numbers. (see Table 10)
(for fault correction see Appendix C)
/C shows when the setup has been altered from the
defaults. (Apollo 1 and Apollo 2 only)
For Apollo 3, the letter behind the "/" sign indicates the
state of modification of the hardware. (board)
Operative time : Cumulative operating time of the printer
Number of labels: Cumulative amount of printed labels
Thermal transfer: Cumulative length of printed material in thermal transfer
mode
Thermal direct : Cumulative length of printed material in direct thermal mode
Date/Time : Setting of system date and system time
Character set : Setting of the "Character set" parameter
Temperature : Printhead temperature
Heat voltage : Current value of heat voltage (approx. 24V)
Brightness : Service information on brightness used at gap sensor
Peripheral device: Type of device connected to peripheral port
Memory card : Type and capacity of memory card (PCMCIA/PC card)
73cab - Produkttechnik GmbH / Tharo Systems, Inc.
Error code
Type of error
HEX DEC
0001 1 dRAM fault
0002 2 dRAM multiplexer fault
0004 4 A/D converter fault
0008 8 Ribbon saver fault
0010 16 sRAM fault
0020 32 LCD damaged
0040 64 Cutter fault
0080 128 ROM fault
0100 256 Voltage fault (Apollo 3)
0200 512
0400 1024
0800 2048
1000 4096
2000 8192
4000 16384 Wrong board revision (Apollo 3)
8000 32768 Setup invalid
For the test result, the codes of occurred errors are added up to a four-digit
hexadecimal number to determine the final test result.
For example : Ribbon saver fault + LCD damaged : Test result = 0028
Table 10 Self test - Test result error codes
3 Bar Code with Test Information
This special bar code is designed for use by Technical Service. It contains
compressed information about the current configuration of the Apollo as well
as previously occurred faults.
74 cab - Produkttechnik GmbH / Tharo Systems, Inc.
5 Test Pattern
The test pattern field contains seven areas with different stroke patterns.
With these patterns a range of print faults can be analyzed. The printout shows
errors such as varying print intensity which indicates the printhead being
misadjusted or dirty, or missing ink dots causing vertical white lines.
4 Existing Character Sets
No. : Identification No. of the font for programming
(command T)
Name : Name of font used for internal storing
Name of command (query sequence) q...CR
Type : Method of generating the characters
(see programming of command T)
Description : Font description (size, type)
