A-2 A1-1 Unit Layout B1. XY θ Assy XY θ T ab le Assy B2. Z Assy Z T able Assy B3. Assy Outer shape control unit Assy B8. Assy Conv eyer Assy B5. Assy Camera Assy B4. XY Assy Camera XY Assy B6. Assy Squeegee driving A…
A-1
Unit Layout
A1./Unit Layout...............................................................................................A-2
A-2
A1-1
Unit Layout
B1. XYθ Assy
XYθ Table Assy
B2. Z
Assy
Z Table Assy
B3.
Assy
Outer shape control unit Assy
B8.
Assy
Conveyer Assy
B5.
Assy
Camera Assy
B4.
XY Assy
Camera XY Assy
B6.
Assy
Squeegee driving Assy
B7.
Assy
Squeegee hanger Assy
C1.
Assy
Squeegee holder Assy
B9-1,B9-2,B9-3. Assy
Frame Assy
A-3
A1-2
Unit Layout
C2-1.
Cleaning (Common)
C2-4.
Paper type Vacuum
Separaton Type L Size
C2-5.
Paper type Vacuum
Separaton Type M Size
C2-2. L
Cloth type L Size
C2-3. M
Cloth type M Size
B10. Assy
Touch panel Assy
B11. Assy
Electric installation Assy
C4.
Vacuum block
C3.
Pin base
C2-6. ペーパーフィルタータイプ
Paper Filter type
