A-3 A1-2 Unit Layout C2-1. Cleaning (Common) C2-4. Paper type V acuum Separaton T ype L Size C2-5. Paper type V acuum Separaton T ype M Size C2-2. L…
A-2
A1-1
Unit Layout
B1. XYθ Assy
XYθ Table Assy
B2. Z
Assy
Z Table Assy
B3.
Assy
Outer shape control unit Assy
B8.
Assy
Conveyer Assy
B5.
Assy
Camera Assy
B4.
XY Assy
Camera XY Assy
B6.
Assy
Squeegee driving Assy
B7.
Assy
Squeegee hanger Assy
C1.
Assy
Squeegee holder Assy
B9-1,B9-2,B9-3. Assy
Frame Assy
A-3
A1-2
Unit Layout
C2-1.
Cleaning (Common)
C2-4.
Paper type Vacuum
Separaton Type L Size
C2-5.
Paper type Vacuum
Separaton Type M Size
C2-2. L
Cloth type L Size
C2-3. M
Cloth type M Size
B10. Assy
Touch panel Assy
B11. Assy
Electric installation Assy
C4.
Vacuum block
C3.
Pin base
C2-6. ペーパーフィルタータイプ
Paper Filter type
