Assembly Instructions / Montageanleitung SIPLACE TX Series

Option 120 V 04/2017

► Release of stored energy:

Energy stored as compressed air in the compressed air supply or electrical energy stored in

electrolytic capacitors must be released by appropriate means.

After switching off the machine, wait until the voltages have discharged and the compressed

air has released, so that work can be performed without any risk.

DANGER

Checking for absence of voltage!

► Before you start working, check the power supply for absence of voltage and observe

the waiting times!

► Testing the lock out:

The lock can be easily tested by pressing the START button.

The following steps must be taken to restore the machine to operation.

► Check the workspace. Authorized employees should remove all of their tools and reinstall all

safety features.

► Notify all affected employees.

► Before removing even one lock or tag, inform all workers in the affected area that the machine

is going to be restarted.

► Remove all locks/tags.

Every authorized employee must remove his own lock and shut it away.

► Switch on the machine. Make sure that authorized staff check the equipment in operation to

ensure that all repairs were performed correctly.

Testing

Service personnel may test circuits by energizing them briefly without suspending the Lock Out /

Tag Out Procedure. This may only be done when no other work is being performed by any other

person on the equipment being tested.

It is extremely important that all remote START switches are tagged with the "Do Not Operate" tag

to prevent inadvertent operation of the equipment during these periods.

Responsibilities

●

It shall be the responsibility of the maintenance and service personnel to make sure this pro-

cedure is adhered to.

●

It shall be the responsibility of the maintenance and service personnel's immediate supervisor

to instruct their personnel on this procedure.

●

It shall be the responsibility of the Safety Officer to administer the Lock Out / Tag Out Proced-

ure.

Assembly Instructions / Montageanleitung SIPLACE TX Series

Option 120 V 04/2017

1 Introduction

1.3 Other Instructions

1.3.1 Environmentally-Friendly Disposal of Materials and Components

SIPLACE products are manufactured using only materials and parts that can be easily separated

and disposed of in an environmentally-friendly way.

NOTICE

Observe the applicable regulations

The company operating the system has sole responsibility for the proper, environmentally-

friendly disposal of machines, working materials, consumables and wear parts.

► Please observe your national statutory provisions for waste disposal and environ-

mental protection.

1.3.2 Use of Original SIPLACE Accessories and Spare Parts

Only use original spare parts and authorized accessories. The use of other parts will affect safety

and will invalidate the liability for any consequential damage.

1.3.3 ESD Guidelines

1.3.3.1 Definition of ESD

Almost all of the modules in use today are equipped with highly integrated Metal-Oxide-Semicon-

ductor (MOS) blocks and components. The manufacturing techniques used mean that these elec-

tronic components are extremely sensitive to overvoltage and thus to electrostatic discharge.

Fig.3: ESD label

The abbreviation for such modules is "ESD"(Electrostatic Sensitive

Device). This is used internationally, although the German abbreviation

"EGB" may also be seen. The following symbol on cabinet rating plates,

racks or packaging indicates that components which are sensitive to elec-

trostatic discharge have been used and thus that the modules concerned

are also touch-sensitive.

ESDs can be destroyed by voltages and electrostatic charges that are far below the level that can

be perceived by humans. Such voltages occur if a person touches a component or module

without earthing themselves. Components that are exposed to such overvoltage do not generally

appear to be defective immediately - incorrect behavior starts after the component or module has

been in operation for some time.

1.3.3.2 Important Measures to Protect Against Static Charging

► Most plastics can easily become charged and must therefore be kept away from at-risk com-

ponents.

► Always ensure that people, the workplace and packaging are safely earthed when handling

electrostatic sensitive components.

1 Introduction

1.3 Other Instructions

Assembly Instructions / Montageanleitung SIPLACE TX Series

Option 120 V 04/2017

1.3.3.3 Handling ESD Modules

Do not touch electronic modules unless it is absolutely essential to do so in order to carry out other

work. If it is necessary, make sure that you do not touch the pins or printed conductors when you

pick up flat modules.

Do not touch components unless

●

You are constantly earthed by an ESD wrist strap or

●

You are wearing ESD shoes or ESD shoe earthing strips on an ESD floor.

Always discharge yourself before you touch an electronic module. To do this, simply touch a con-

ductive and earthed object immediately before you touch the module (such as unpainted parts of a

switch cabinet, a water pipe, etc.).

Do not allow modules with chargeable and highly insulating materials to touch one another, e.g.

plastic films, insulating table surfaces or items of clothing made from synthetic fibers.

Always place the modules on a conductive surface (table with an ESD coating, conductive ESD

foam, ESD bag or container).

Do not bring modules near visual display units, monitors or televisions. Keep them at least 10cm

away from the screen.

1.3.3.4 Measurements and Modifications to ESD Modules

Measurements of the assemblies may only be taken if

●

The measuring device has been grounded (e.g. via protective conductor) or

●

you discharge the measuring head before taking measurements with a potential-free measur-

ing device (e.g. by touching an unpainted metal part of the controller casing).

► Always use an earthed soldering iron if you carry out any soldering work.

1.3.3.5 Dispatching ESD Modules

► Always store modules and components in conductive packaging (e.g. metalized plastic bags

or metal sleeves) and dispatch them in conductive packaging.

► If the packaging is not conductive, place the modules in a conductive envelope before pack-

aging. Use conductive expanded rubber, ESD bags, domestic aluminum foil or paper, for ex-

ample.

► If the module has integral batteries, ensure that the conductive packaging does not touch or

short-circuit the battery terminals and, if necessary, first cover the terminals with insulating

tape or material.

1.3.4 Validity of Document

This document is valid for the following machine types:

●

SIPLACE TX Series

The work described in this manual is divided into modules, and to a large extent, it is identical for

all machine types:

●

If the work required for specific machines differs from the standard procedure, this will be in-

dicated with reference to the machine number, series and delivery state.

●

Illustrations are only shown as examples, for example, the illustration of a specific machine

type or a machine with different paint finish does not imply that the information following the il-

lustration only applies to the shown machine type.

Please read the circuit diagram folder for any electrical checks.
