QP-242E-11 - 第235页
63.2.本体(BHAB) 63.2.Body(BHAB) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 No. Drg. No. & Code No. QTY Description Rating Remarks 1 BHAB0021 1 COLUMN ｺﾗﾑ **-6** 2 BHAB0030 1 LEG 脚 3 BHAB0040 1 LEG 脚 4 BHAB0056 1 LEG 脚 5 BHAB0067 1…
A
B
B
A
＊S-7＊＊
＊＊-8＊＊
B
B
A
＊＊-8＊＊
＊I-7＊＊
A
＊I-6＊＊
39
44
35
69
56
46
49
56
46
49
39
44
68
68
42
52
42
52
42
52
42
52
42
52
42
52
1
82
44
48
22
23
37
21
45
40
2
3
5
83
84
85
86
4
12
11
54
54
16
16
19
19
36
44
38
44
38
44
38
19
19
17
17
65 66
44
38
19
19
44
38
44
38
18
18
15
61
67
46
58
57
57
34
70
35
69
34
70
＊S-6＊＊
71
73
74
74
74
75
46
76
72
44
38
81
44
78
79
77
83
QP-242E PARTS LIST ver11
63 - 4
63.2.本体(BHAB)
63.2.Body(BHAB)
63.2.本体(BHAB)
63.2.Body(BHAB)
63.2.本体(BHAB)
63.2.Body(BHAB)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No.
Drg. No. & Code No.
QTY Description Rating Remarks
1 BHAB0021 1 COLUMN ｺﾗﾑ **-6**
2 BHAB0030 1 LEG 脚
3 BHAB0040 1 LEG 脚
4 BHAB0056 1 LEG 脚
5 BHAB0067 1 LEG 脚
11 BHAB0130 1 GUIDE ｶﾞｲﾄﾞ
12 BHAB0130 1 GUIDE ｶﾞｲﾄﾞ **-6**
15 BHAB0260 1 BKT BKT **-6**
16 BHAB0310 2 BOLT ﾎﾞﾙﾄ
17 BHAB0320 2 BOLT ﾎﾞﾙﾄ
18 BHAB5060 2 BOLT ﾎﾞﾙﾄ
19 BHAB0360 2 BKT BKT
21 MPQ0132 1 BKT BKT
22 MPQ0141 1 CLAMP ｸﾗﾝﾌﾟ
23 MPQ0150 1 PLATE, RUBBER ﾌﾟﾚｰﾄ ｺﾞﾑ
34 BHSY0190 2 PLATE ﾌﾟﾚｰﾄ
35 BHSY0200 2 RETAINER, WIRING 押え 配線
36 K5335E 6 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ JSU6 *I-6**, *I-7**
37 K1133A 1
CAMERA, CCD
ｶﾒﾗ CCD IK-541
38 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L
39 H5294A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X30L
40 H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L
42 H5388A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M12X35L
44 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
45 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
46 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
48 W1043A
WASHER, FLAT
ﾜｯｼｬ 平
4W-4
49 W1045A
WASHER, FLAT
ﾜｯｼｬ 平
4W-6
52 W1016A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-12-H
54 K5359E
SCREW, COUNTERSUNK
小ﾈｼﾞ 皿
M4X8L
56 K52613
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M6X8L
57 K4147H 2
FLEXIBLE TRACK
ｹｰﾌﾞﾙﾍﾞｱ 25.2-055-16-22B **-6**
58 BHAB5029 1 COLUMN ｺﾗﾑ **-7**
61 BHAB5030 2 BKT BKT **-7**
65 K5335E 10 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ JSU6 *S-6**
66 K5335E 8 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ JSU6 *S-7**,**-8**
67 H5321A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X12L
QP-242E PARTS LIST ver11
63 - 5
63.2.本体(BHAB)
63.2.Body(BHAB)
63.2.本体(BHAB)
63.2.Body(BHAB)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No.
Drg. No. & Code No.
QTY Description Rating Remarks
68 K4147T 2
FLEXIBLE TRACK
ｹｰﾌﾞﾙﾍﾞｱ 25.3-055-16-13B **-7**
69 BHSY5030 2 PLATE ﾌﾟﾚｰﾄ
70 BHSY5040 2 RETAINER, WIRING 押え 配線
71 BHAB6027 1 COLUMN ｺﾗﾑ **-8**
72 BHAB6031 1 BKT BKT **-8**
73 BHAB0140 1 MANIFOLD, AIR ﾏﾆﾎｰﾙﾄﾞ ｴｱｰ
74 Y3054A 3 ELBOW ｴﾙﾎﾞ KQL08-02S
75 Y3058L 1 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KQH16-04S
76 H5320A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X10L
77 BHPH4580 1 BKT BKT
78 BHAB0700 1 BKT BKT
79 A10381 1 AMPLIFIER ｱﾝﾌﾟ AP-80A
80 BHGC4191 1 BKT BKT
81 H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X20L
82 H5285A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X5L
83 BHPZ0042 1 NAMEPLATE 銘板 Japanese/English
84 BHPZ0122 1 NAMEPLATE 銘板 Japanese/French
85 BHPZ0081 1 NAMEPLATE 銘板 Japanese/English
86 BHPZ0111 1 NAMEPLATE 銘板 Japanese/French
QP-242E PARTS LIST ver11
63 - 6
63.2.本体(BHAB)
63.2.Body(BHAB)
