QP-242E-11 - 第257页
QP-242E P ARTS LIST ver1 1 6 8 - 4 6 8 . 2 . M F U - 5 8 L E , M F U - 5 8 S E 本体( B H U F ) 6 8 . 2 . M F U - 5 8 L E , M F U - 5 8 S E B o d y ( B H U F ) 6 8 . 2 . M F U - 5 8 L E , M F U - 5 8 S E 本体( B H U F ) 6 8 .…
68.1.MFU-58LE,MFU-58SE 本体(BHUF)
68.1.MFU-58LE,MFU-58SE Body(BHUF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No.& Code No. QTY Description Rating Remarks
38 BHUF0640 1 PLATE ﾌﾟﾚｰﾄ
39 BHUF6120 1 MANIFOLD ﾏﾆﾎｰﾄﾞ
40 S5021M 31 SOCKET ｿｹｯﾄ SMK-015
41 S2171B 1 JOINT, ONE-TOUCH ｼﾞｮｲﾝﾄ ﾜﾝﾀｯﾁ TL6-01(NYﾒｯｷ)
42 K51721 5 SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M3X5L
43 K51725 3 SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M5X25L
44 IPA0580 1 SEAL ｼｰﾙ
45 IPA5340 1 SEAL ｼｰﾙ
46 IPA5350 1 SEAL ｼｰﾙ
47 KPA0890 2 SEAL ｼｰﾙ
48 BHUF0650 2 NAMEPLATE, CAUTION 銘板注意 English
49 H3085T 2 BUSHING, RUBBER ﾌﾞｼｭ ｺﾞﾑ G-12
50 BHUF0770 1 NAMEPLATE 銘板
51 BHUF0800 1 NAMEPLATE, CAUTION 銘板注意 English
52 BHUF0780 1 NAMEPLATE 銘板
53 BHUF0810 2 NUT ﾅｯﾄ
54 BHUF0830 2 NAMEPLATE, CAUTION 銘板注意 French
55 BHUF0840 1 NAMEPLATE, CAUTION 銘板注意 French
56 ABHUF6130 1 DOOR 扉 Smoke(Option)
57 ABHUF6190 1 DOOR 扉 Clear(Option)
58 ABHUF6150 1 DOOR 扉 For Handy terminal
59 BHPZ0170 1 SEAL ｼｰﾙ Brown smoke
60 WWM0210 1 SEAL ｼｰﾙ Clear(Option)
61 BHUF0720 1 BKT BKT
62 H5299A 4 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L
63 W1023A 4 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
64 H1051Z 1 VALVE, CHECK ﾊﾞﾙﾌﾞ ﾁｪｯｸ HT-720-02
65 A1022E 2 ADAPTER ｱﾀﾞﾌﾟﾀ 1034-6-1/4
66 A10208 1 ADAPTER ｱﾀﾞﾌﾟﾀ 1010-6-1/4
67 BHUF6140 1 BASE ﾍﾞｰｽ MFU-5SE-Type
68 KPD5040 1 SEAL, BAR CODE ｼｰﾙ ﾊﾞｰｺｰﾄﾞ For Handy terminal
69 BHUF6220 1 SEAL ｼｰﾙ For Handy terminal
70 BHTB6030 1 GUIDE, TAPE ｶﾞｲﾄﾞ ﾃｰﾌﾟ For STU-1 1set
71 BHTB6010 1 SEAL ｼｰﾙ For STU-1 1set
72 BHTB6040 1 GUIDE, TAPE ｶﾞｲﾄﾞ ﾃｰﾌﾟ For STU-1 2set
73 BHTB6020 1 SEAL ｼｰﾙ For STU-1 2set
QP-242E PARTS LIST ver11
68 - 3
68.1.MFU-58LE,MFU-58SE 本体(BHUF)
68.1.MFU-58LE,MFU-58SE Body(BHUF)
QP-242E PARTS LIST ver11
68 - 4
68.2.MFU-58LE,MFU-58SE 本体(BHUF)
68.2.MFU-58LE,MFU-58SE Body(BHUF)
68.2.MFU-58LE,MFU-58SE 本体(BHUF)
68.2.MFU-58LE,MFU-58SE Body(BHUF)
18
18
5
19
18
18
5
19
18
5
18
19
18
5
18
19
3
17
17
21
20
4
20
2
17
17
12
11
24
21
25
22
22
13
6
15
14
9
16
8
23
23
1
27
28
36
10
30
32
34
33
31
29
26
24
25
26
37
35
30
32
34
33
31
35
38
7
H=962
H=962
68.2.MFU-58LE,MFU-58SE 本体(BHUF)
68.2.MFU-58LE,MFU-58SE Body(BHUF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No.& Code No. QTY Description Rating Remarks
1 BHUF6040 1 FRAME ﾌﾚｰﾑ
2 BHUF6050 1 LINK ﾘﾝｸ
3 BHUF6260 1 LINK ﾘﾝｸ
4 BHUF6070 1 SHAFT ｼｬﾌﾄ
5 BHUF0550 4 ROLLER ﾛｰﾗ
6 BHUF6230 1 COVER 蓋
7 H5326A 6 NBOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X25
8 BHUF6241 1 CYLINDER ｼﾘﾝﾀﾞ
9 BHUF6250 1 ROD ﾛｯﾄﾞ
10 BHUF6170 1 HOSE, HYDRAULIC ﾎｰｽ 油圧
11 H2015G 1 PIN ﾋﾟﾝ CCG10-55
12 H20150 1 PIN ﾋﾟﾝ CCG10-33
13 S3006A 1
SCRAPER
ｽｸﾚｰﾊﾟ SDR-30
14 H1184W 1 PACKING ﾊﾟｯｷﾝ ISI-30
15 R2063Z 1 RING, BACKUP ﾘﾝｸﾞ ﾊﾞｯｸｱｯﾌﾟ SDR-30
16 A5115A 1 0 RING O ﾘﾝｸﾞ P=44
17 H20315 4 PIN, SPRING ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ 10ﾟX22
18 M1061X 8 WASHER ﾜｯｼｬ SSWA17-2.0
19 S1026A 4
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-8
20 W1057A 2 WASHER, FLAT ﾜｯｼｬ 平 12M/MX2.5X24(1W-12)
21 H2099T 2 PIN, SPLIT ﾋﾟﾝ 割 2.5ﾟX15
22 H4332A 2
BEARING, DRY
ﾍﾞｱﾘﾝｸﾞ ﾄﾞﾗｲ MB1010DU
23 H4333H 2
BEARING, DRY
ﾍﾞｱﾘﾝｸﾞ ﾄﾞﾗｲ MB1020DU
24 K21405 2 CASTER, UNIVERSAL ｷｬｽﾀ 自在 NO.104HB2-EP(19081)
25 K5262A 8 SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ 六角穴ﾎﾞﾀﾝ M6X10L
26 W1024A 8 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
27 BHUF0760 1 BKT BKT
28 H5320H 2 NBOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X10L
29 W1024A 2 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
30 K2023N 2 CASTER ｷｬｽﾀ PH-50
31 BHUF0860 2 BKT, ROLLER BKT ﾛｰﾗ
32 K5201A 2 NBOLT, HEX ﾎﾞﾙﾄ 六角 M8X50L 10.9
33 N1068A 2 NUT, U ﾅｯﾄ U M08
34 K5262A 4 SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ 六角穴ﾎﾞﾀﾝ M6X10L
35 W1024A 4 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
36 A1022C 1 ELBOW ｴﾙﾎﾞ 1033-6-1/4,
QP-242E PARTS LIST ver11
68 - 5
68.2.MFU-58LE,MFU-58SE 本体(BHUF)
68.2.MFU-58LE,MFU-58SE Body(BHUF)
