91.STU-1(オプション)(BHTB) 91.STU-1(Option)(BHTB) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 No. Drg. No. & Code No. QTY Description Rating Remarks 76 Y3069A 1 UNION ﾕﾆｵﾝ KQ2R06-10 77 T50122 1 HANDLE 取手 THA-31SUS(No.5) 78 W1004E 2 WA…
91.STU-1(オプション)(BHTB)
91.STU-1(Option)(BHTB)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No.
Drg. No. & Code No.
QTY Description Rating Remarks
39 BHTB0840 1 DOG ﾄﾞｯｸﾞ
40 BHTB0850 1 BKT BKT
41 BHTB0861 1 BKT BKT
42 BHTB0870 1 LINK ﾘﾝｸ
43 BHTB0880 1 BKT BKT
44 BHTB0890 1 BKT BKT
45 BHTB0900 1 RAIL ﾚｰﾙ
46 BHTB0910 1 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ
47 BHTB0920 1 COVER ｶﾊﾞｰ
48 BHTB0930 1 BKT, CYLINDER BKT ｼﾘﾝﾀﾞ
49 BHTB0940 1 COVER, WIRING ｶﾊﾞｰ 配線
50 BHTB0951 1 BOX BOX
51 BHTB0960 1 BOLT ﾎﾞﾙﾄ
52 BHTB0970 1 HANDLE 取手
53 BHTB0981 1 BKT BKT
54 BHTB1010 1 BKT BKT
55 BHTB1020 1 SPRING ｽﾌﾟﾘﾝｸﾞ
56 ABHTB1670 2 GUIDE, SIDE ｶﾞｲﾄﾞ ｻｲﾄﾞ
57 FPH1091 1 NOZZLE ﾉｽﾞﾙ
58 FPH1400 1 PAD ﾊﾟｯﾄ
59 KPA0100 1 COLLAR ｶﾗｰ
60 S21347 1
CYLINDER, RODLESS
ｼﾘﾝﾀﾞ ﾛｯﾄﾞﾚｽ CY1B10H-380
61 M5056F 1
MOTOR, REVERSIBLE
ﾓｰﾀ ﾘﾊﾞｰｼﾌﾞﾙ PB206-401
62 H4006T 1
HEAD, GEAR
ﾍｯﾄﾞ ｷﾞﾔ 2GN-12.5K
63 Y3079N 1
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L06-M5
64 Y3080A 2 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L10-02S
65 S4040W 3 SENSOR ｾﾝｻ EE-SPX305-W2A-2M
66 S4040X 2 SENSOR ｾﾝｻ EE-SPX306-W2A-2M
67 S3141E 4
SW, PHOTOELECTRIC
SW 光電
FTV74BC
68 A1040T 2
AMPLIFIER
ｱﾝﾌﾟ F2R
69 K2021Z 2 GEAR, MITER ｷﾞﾔ ﾏｲﾀ MIS20+2108
70 H4131A 1
BEARING
ﾍﾞｱﾘﾝｸﾞ 698ZZ
71 H4141T 1
BEARING
ﾍﾞｱﾘﾝｸﾞ MF126ZZ
72 S1022A 14
CIR-CLIP, E-TYPE
ｻｰｸﾘｯﾌﾟ E形
E-4
73 H11217 1
VALVE, SOL
ﾊﾞﾙﾌﾞ SOL VJ5420-5LZ-M5
74 H1130A 1
VALVE, SOL
ﾊﾞﾙﾌﾞ SOL VXD2130-02-5G-B
75 Y3043L 1
UNION
ﾕﾆｵﾝ KQ2Y10-02S
QP-242E PARTS LIST ver11
91 - 3
91.STU-1(オプション)(BHTB)
91.STU-1(Option)(BHTB)
91.STU-1(オプション)(BHTB)
91.STU-1(Option)(BHTB)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No.
Drg. No. & Code No.
QTY Description Rating Remarks
76 Y3069A 1
UNION
ﾕﾆｵﾝ KQ2R06-10
77 T50122 1 HANDLE 取手 THA-31SUS(No.5)
78 W1004E 2 WASHER ﾜｯｼｬ THA-270(No.3)3460
79 H2056A 1
PIN, SPRING
ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ 4ﾟX14
80 H5066T 1 BALL, STEEL ﾎﾞｰﾙ ｽﾁｰﾙ 4.5mm
81 Y3049G 2
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KJL04-M5:白
82 S4027B 2 SENSOR ｾﾝｻ E32-T14L
83 A1038M 1
AMPLIFIER
ｱﾝﾌﾟ E3X-H11
84 K5335A 4
CONTROLLER, SPEED
ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ JSU4
85 Y3086W 2 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KQ2S04-M5
86 H5246T BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M2X4L
87 .
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M2X20L
88 H5273T
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X4L
89 H5273A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X5L
90 H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X6L
91 H5275A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8L
92 H5276A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L
93 H5277A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X12L
94 H5278A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X15L
95 H5285A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X5L
96 H5286A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X6L
97 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L
98 H5288A BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L
99 H5290A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X15L
100 H5293A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X25L
101 H5297A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X8L
102 H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L
103 H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L
104 H5300A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X15L
105 W1020A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2M/M
106 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
107 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
108 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
109 W1042A
WASHER, FLAT
ﾜｯｼｬ 平
4W-3
110 W1043A
WASHER, FLAT
ﾜｯｼｬ 平
4W-4
111 W1044A
WASHER, FLAT
ﾜｯｼｬ 平
4W-5
112 W1010A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-3-L
QP-242E PARTS LIST ver11
91 - 4
91.STU-1(オプション)(BHTB)
91.STU-1(Option)(BHTB)
91.STU-1(オプション)(BHTB)
91.STU-1(Option)(BHTB)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No.
Drg. No. & Code No.
QTY Description Rating Remarks
113 W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-4-L
114 N4017A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M2X3L
115 N4014A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M3X4L
116 N4027A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M4X5L
117 . SCREW, COUNTERSUNK 小ﾈｼﾞ 皿 M2X4L
118 . SCREW, COUNTERSUNK 小ﾈｼﾞ 皿 M3X4L
119 . SCREW, COUNTERSUNK 小ﾈｼﾞ 皿 M4X4L
120 K5173A
SCREW, C/R PAN
小ﾈｼﾞ 十穴鍋
M3X10L
121 BHTB1050 1 PLATE ﾌﾟﾚｰﾄ
122 W1004R WASHER ﾜｯｼｬ WSF10
123 K5201E SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M2.6X6L
124 BHTB1070 1 GUIDE ｶﾞｲﾄﾞ
125 K5203A SCREW, C/R TRUSS 小ﾈｼﾞ ﾄﾗｽ M3X6L
126 BHTB0441 1 BASE ﾍﾞｰｽ ･
QP-242E PARTS LIST ver11
91 - 5
91.STU-1(オプション)(BHTB)
