Key No. PART No. PART NAME Q'ty REMARKS REGISTERED No.
57 411 141 4107 WASHER V 5X10X1 2 FW5
58 411 141 6705 WASHER SPR 5 2 SW5
59 630 000 7763 BOLT,HEX-SCT 2 M5X16
61 630 054 4299 WIRE PARTS 1 648BC-11H-514
62 411 141 4305 WASHER V 6X12.5X1.6 8 FW6
63 411 141 3001 WASHER SPR 6 8 SW6
64 630 000 7909 BOLT,HEX-SCT 4 M6X25
64 -1 411 141 0703 NUT HEX 6 4 M6
66 411 141 5203 WASHER V 16X30X3 8 FW16
67 411 141 3407 WASHER SPR 16 8 SW16
68 630 000 8340 BOLT,HEX-SCT 8 M16X60
71 630 054 4572 COVER(Y-SERVO CABLE) 1 648BC-11B-085
72 411 141 4008 WASHER V 4X9X0.8 2 FW4
73 411 141 2905 WASHER SPR 4 2 SW4
74 630 000 7626 BOLT,HEX-SCT 2 M4X10
75 411 141 4107 WASHER V 5X10X1 1 FW5
76 411 141 6705 WASHER SPR 5 1 SW5
77 630 000 7749 BOLT,HEX-SCT 1 M5X10
78 630 001 0244 WASHER 8 BW8
79 411 141 3100 WASHER SPR 8 1 SW8
80 630 000 7992 BOLT,HEX-SCT 1 M8X12
81 411 113 9703 SCR TRS 6X10 1 M6X10 TRS
NOTE
2-1
9703-001
MODEL TIM-1000L
