Installation Manual Station Software Version 505.04 38 of 156 Menu item Note Selection options Aw ard Preboot Agent If this option is Enabled , all video outputs based on INT10 (e.g. all outputs made during the POST), ar…

100%1 / 156
Installation Manual, Station Software Version 505.04 Edition 07/2006
37 of 156
Menu item Note Selection
options
Swap Floppy Drive
If the drive letters assigned to floppy drives are to be
exchanged, this field must be set to Enabled.
Enabled
Disabled
Boot Up Floppy
Seek
If this option is enabled, the BIOS looks for the floppy
drive A once
Enabled
Disabled
Boot Up Numlock
Status
The user can enable the NumLock function here (numbers
on the numeric block on the keyboard) when the system
boots.
On
Off
Gate A20 Option
When Fast is set, the keyboard controller switches Gate
A20, otherwise the processor does this.
Normal
Fast
Typematic Rate
Setting
When this field has been enabled, the following two
keyboard settings appear.
Enabled
Disabled
Typematic Rate
(Chars/Sec)
This field controls the speed at which the system registers
a key which is pressed and held as a keystroke.
6; 8; 10; 12; 15;
20; 24; 30
Typematic Delay
(msec)
This field controls the delay before keystrokes begin to
repeat.
250; 500; 750;
1000
Security Option
This determines when the system requests the password
(password: see PASSWORD SETTING).
System: The password is requested every time the system
boots.
Setup: The password is only requested when you call the
Setup utility.
Setup
System
APIC Mode
Under Windows 2000 and Windows XP, more interrupts
are available when this option is enabled
Disabled
Enabled
MPS Version
Control For OS
1.1
1.4
OS Select For
DRAM > 64MB
If the system operates under OS/2 with main memory
greater than 64 MB, this option must be set to OS2.
Non-OS2
OS2
HDD S.M.A.R.T
Capability
SMART (Self Monitoring Analyse and Reporting
Technology) is implemented in modern hard disks. This
technology can detect reading or rotational speed
problems. Data is read with the appropriate software.
Disabled
Enabled
Installation Manual Station Software Version 505.04
38 of 156
Menu item Note Selection
options
Award Preboot
Agent
If this option is Enabled, all video outputs based on INT10
(e.g. all outputs made during the POST), are additionally
output via a serial interface to a connected, VT100-
compatible terminal. Keystrokes which are based on INT16
can also be made on the VT100 keyboard.
If this option is Enabled and no terminal or no VT100-
compatible terminal is connected, the following message
appears when the system is started up
"Award Preboot Agent Installation Failed"
The terminal must be set to the following values:
Transfer rate 19200 Baud
Data Bits 8
Stop Bits 1
Enabled
Disabled
Agent after Boot
If the preboot agent is enabled, this option can be used to
set whether the console is still to be redirected (enabled) at
the beginning of the boot process or to be disabled when
the POST is finished.
Disabled
Enabled
Report No FDD For
WIN 95
If this option is set to Yes, no floppy drive will be registered
in Windows 95.
No
Yes
C8000-CBFFF
CC000-CFFFF
D0000-D3FFF
D4000-D7FFF
D8000-DBFFF
DC000-DFFFF
Shadow
If this option is enabled, a BIOS extension which is found
in this address range is copied to the same address in
main memory, for the purpose of faster execution.
Disabled
Enabled
Small Logo (EPA)
Show
This specifies whether the EPA logo is displayed in the top
right corner of the monitor when the system is started
Enabled
Disabled
4.3.1.8 Setup page "Advanced Chipset Features"
In the "Selection options" column, the setting for fail-safe default is indicated in italics and the setting
for optimized default is underlined
.
Menu item Note Selection options
SDRAM CAS latency
Time
The latency time between a SDRAM read command and
the actual availability of the data is set here.
Auto
2
3
SDRAM Cycle Time
Tras/Trc
This option is used to specify the time for which a memory
cell of the SDRAM is kept open in order to access the cells
available in the same line
7/9
5/7
Auto
Installation Manual, Station Software Version 505.04 Edition 07/2006
39 of 156
Menu item Note Selection options
SDRAM RAS-to-CAS
Delay
The delay between the SDRAM enable command and the
SDRAM read/write command can be changed in this field.
2
3
Auto
SDRAM RAS
Precharge Time
The time after a precharge command for a bank until the
bank can be accessed.
2
3
Auto
System BIOS
Cacheable
This function enables the system to cache the BIOS area
as well.
Enabled
Disabled
Video BIOS
Cacheable
This function enables the system to cache the VGA-BIOS
area as well.
Enabled
Disabled
Memory Hole At
15M-16M
If this function is enabled, the memory hole from 15 MB
through 16 MB is reserved for ISA expansion boards which
require this setting. Depending on the operating system
used, the memory ceases to be available to the system as
of 15 MB. Expansion boards can only address memories
of up to 16 MB.
Enabled
Disabled
CPU Latency Timer
Enabled
Disabled
Delayed Transaction
When set to Enabled, this option enables the 32-bit write
buffer for PCI access.
Enabled
Disabled
System Memory
Frequency
The memory frequency can be specified here, if a
processor supporting both 100MHz and 133MHz memory
frequency has been fitted. If a processor which only
supports 100MHz memory frequency has been fitted (e.g.
Celeron 566MHz), this menu item will not be visible.
100MHz
133MHz
Auto
4.3.1.9 Setup page "Integrated Peripherals Feature"
In the "Selection options" column, the setting for fail-safe default is indicated in italics and the setting
for optimized default is underlined
.
Menu item Note Selection options
On-Chip Primary
PCI IDE
Enabling this field enables the primary IDE channel on
which devices can be run.
Enabled
Disabled
On-Chip Secondary
PCI IDE
Enabling this field enables the secondary IDE channel on
which devices can be run.
Enabled
Disabled
IDE Primary Master
PIO
Sets the PIO mode for the master on the primary IDE
channel. Higher values mean faster access. Auto sets the
maximum permissible value for the disk.
Auto; Mode 1;
Mode 2; Mode 3;
Mode 4
IDE Primary Slave
PIO
Sets the PIO mode for the slave on the primary IDE
channel. Higher values mean faster access. Auto sets the
maximum permissible value for the disk.
Auto; Mode 1;
Mode 2; Mode 3;
Mode 4
