Installation Manual, Station Software Version 505.04 Edition 07/2006
53 of 156
Warning:
The C: partition will be formatted. All data which has not been saved will now be deleted.
→ Confirm your selection with <RETURN>. The installation is then continued.
→ You are now requested to insert the floppy MCRMOS Disk -1/2- into the drive.
→ After both floppies have been installed, the message “Installation finished“ appears.
The operating system has been completely installed.
→ Now remove the floppy from the drive and switch the machine off and then on again.
4.3.3.3 Changing the network addresses
To change the internet addresses, you must
- Switch the machine off
- Insert installation floppy #1 and switch the machine on
- Press the key 'A' in the first menu
- The menu offers you the choice of setting the internet addresses or the port IDs.
[X] EXIT MENU [H] SET INTERNET ADDRESS
[S] SET PO RT ID
PRESS KEY TO CONTINUE [H,S,X]?
If 'H' is selected, the file '\ETC\HOSTS' appears in the DOS editor.
The Internet addresses and system names valid for this station must be entered.
Note:
The ALIAS names "autlr", "autsr" and "localhost" must not be changed, as these names
are used and required by the software.
Installation Manual Station Software Version 505.04
54 of 156
Example of hosts:
#******************************************************************************
#
# File : C:\ETC\HOSTS
#
# Author/Date : T. Noetzold 16-Aug-1995
#
# Abstract : Konfigurationsdatei fuer TCP/IP
#
# Inskript: : AUT 5 BSM 13 $Author:: ake/mme $
# $Date:: 10 Sep 1996 23:41:16$
# $Revision:: 3.0 $
#
# Usage : Durch TCP/IP-Software
#
#******************************************************************************
# Copyright (C) 1992-1996 by Siemens AG. All rights reserved
#******************************************************************************
#
# Internet Official List Of Aliases # Comment
# Address Host Name
#
127.255 loop
172.22.231.84 local localhost # my IP address!
172.22.231.82 autsr traceserver # station computer
220.9.200.1 autgem # gem computer
# --- end of host file ---
SD EA 1 has a globally unique Class B internet address.
Since the machine controller and the station computer have a separate subnet, the machine
controller only has one unique internet address.
This official Class B internet address is 192.168.255.250. The address of the station computer on
this subnet is 192.168.255.249. We will make the correct settings for you. (This information is also
contained in the machine documents).
Should you have any queries, contact our Service department.
→ If 'S' is selected, the file '\ETC\SERVICES' appears in the DOS editor.
→ If 'X' is selected, the menu is exited and the DOS prompt appears.
→ Remove the floppy disk from the drive.
→ To start the SIPLACE system, switch the machine off and then on again.
Installation Manual, Station Software Version 505.04 Edition 07/2006
55 of 156
4.3.4 Troubleshooting
→ If the installation program terminates prematurely due to an error, remove the floppy from the
drive and switch the machine off.
→ Insert floppy #1 into the drive and switch the machine on again.
→ Try installing the machine controller operating system again.
Note:
If the software can still not be installed on the second attempt,
contact your Service center.
