Installation Manual, Station Software Version 701.02 07/2008 Edition
4.5.4 Selecting the machine type
Fig. 4-12 Selecting the machine type
→ Select the option for the machine type for which the software is to be configured.
→ Click the Next button.
25 of 38
Installation Manual, Station Software Version 701.02 07/2008 Edition
4.5.5 Entering the Machine Identification Number (MID)
26 of 38
Fig. 4-13: Entering the Machine Identification Number (MID)
→ In the text box, enter the 8-digit machine identification number.
Note:
You will find the MID on an adhesive label on the side of the protective covers directly below the
label for the number of the relevant location. The number following the dash after the MID
specifies the location and is not entered here (e.g. 00000001-2 stands for location 2).
→ Click the Next button.
Note:
The following screen only appears if applications are open which use files which must be
updated during installation of SIPLACE.
Fig. 4-14: Open applications
Installation Manual, Station Software Version 701.02 07/2008 Edition
→ Close the applications listed here and then click the Retry button.
The installation program now installs additional programs on the machine computer.
4.5.6 Finalizing the installation
Note:
The status only lists the programs that have just been installed. If, for instance, the current
version of SIPLACE Vision was already installed, it is not listed here.
If errors occurred during installation, the status is indicated by the Error button being
displayed next to the program name instead of the Ok button.
→ If you wish to read the log of the installation of any program, click the Ok (or Error) button next to the
name of the program. The Notepad is started and displays the appropriate file.
Fig. 4-15: Finalizing the installation
→ Click the Finish button.
Caution:
The Vision computer must also
27 of 38
be installed (see section 6) before you shut down the
machine computer, as the station will otherwise not boot correctly due to version conflicts.
