NPM-W 2 EJM7DE-MB-02M-00 2-1-6 -10 8-nozzle head Nozzle reflector contact surface Vacuum air path θ -axis belt Inner and outer circu mferences Spring for nozzle cushion Clamp claw Spring for holding Clamp claws Nozzle ho…
NPM-W2 EJM7DE-MB-02M-00
2-1-6-9
12-nozzle head
* This is shared with the Light weight 16-
nozzle head.
Nozzle flange upper
surface (2D code
area)
Nozzle taper surface
Nozzle tip
Inner and outer
circumferences
Spring for nozzle
cushion
Clamp claw
Spring for holding
Clamp claws
Nozzle reflector
contact surface
Vacuum air path
Nozzle reflector
θ-axis belt
Nozzle holder slicing
surface
Splicing shaft
sliding surface
Nozzle inside
Periodic inspection points
by unit 5
<Placement head> (Option)
Maintenance
2-1-6
Over-
view
■Nozzle holder
■Nozzle changer
■12-nozzle head ■Nozzle
NPM-W2 EJM7DE-MB-02M-00
2-1-6-10
8-nozzle head
Nozzle reflector
contact surface
Vacuum air path
θ-axis belt
Inner and outer
circumferences
Spring for nozzle
cushion
Clamp claw
Spring for holding
Clamp claws
Nozzle holder slicing
surface
Splicing shaft
sliding surface
Nozzle reflector
Nozzle flange upper
surface (2D code area)
Nozzle taper surface
Nozzle tip
Nozzle inside
Overview
■8-nozzle head ■Nozzle
■Nozzle holder
■Nozzle changer
NPM-W2 EJM7DE-MB-02M-00
2-1-6-11
3-nozzle head
Clamp claw
Spring for holding clamp
claws
Taper surface
Nozzle reflector
contact surface
Vacuum air path
θ-axis belt
Nozzle reflector
Nozzle flange
upper surface
(2D code area)
Nozzle tip
Periodic inspection points
by unit 6
<Placement head> (Option)
Maintenance
2-1-6
Over-
view
■Nozzle holder
■Nozzle changer
■3-nozzle head ■Nozzle
