N7201A617E00_0317 - 第111页
NPM-W 2 EJM7DE-MB-02 M-00 2-1-6 -14 Cushion (wiping station) Spring Rack & pinion Linear guide Dummy disp ensing tape Dummy dispensing plate Dummy dispensing unit Wiping station Overview
NPM-W2 EJM7DE-MB-02M-00
2-1-6-13
This is a sectional view for explanation.
O-ring
Screw
Collar
Stopper pin
Spring
Holder inside
O-ring
Nozzle tip
Periodic inspection points
by unit 8
<Dispensing head> (Option)
Maintenance
2-1-6
Over-
view
Dispensing head
Screw unit
Ball screw
Linear guide
Heater/Thermocouple
Joint
Spring
O-ring
O-ring
NPM-W2 EJM7DE-MB-02M-00
2-1-6-14
Cushion (wiping station)
Spring
Rack & pinion
Linear guide
Dummy dispensing tape
Dummy dispensing plate
Dummy dispensing unit
Wiping station
Overview
NPM-W2 EJM7DE-MB-02M-00
2-1-6-15
Maintenance
2-1-6
Over-
view
Periodic inspection points
by unit 9
<Others > (option)
Components-ejection conveyor
Component
detection sensor
Conveyor belt
Height sensor
Front and rear sides
Light-emitting and light-
receiving glasses
