NPM-W 2 EJM7DE-MB-02M-00 2-1-6 -15 Maintenance 2-1-6 Over- view P eriodic inspection points by unit 9 <Others > (option) Components-ejection conveyor Component detection sensor Conveyor belt Height sensor Front and…
NPM-W2 EJM7DE-MB-02M-00
2-1-6-14
Cushion (wiping station)
Spring
Rack & pinion
Linear guide
Dummy dispensing tape
Dummy dispensing plate
Dummy dispensing unit
Wiping station
Overview
NPM-W2 EJM7DE-MB-02M-00
2-1-6-15
Maintenance
2-1-6
Over-
view
Periodic inspection points
by unit 9
<Others > (option)
Components-ejection conveyor
Component
detection sensor
Conveyor belt
Height sensor
Front and rear sides
Light-emitting and light-
receiving glasses
NPM-W2 EJM7DE-MB-02M-00
2-1-6-16
Overview
■Single conveyor
Support pin automatic change
Front and rear sides
PCB-support block
(for automatic
change)
■Nozzle changer for support
pin
■Support pin
(for automatic change)
■Support pin nozzle
Nozzle reflector
Nozzle flange upper
surface
(2D code area)
Nozzle taper surface
Nozzle inside
Nozzle tip
(Vacuum pad)
1100-nozzle
(for 3-nozzle head)
100-nozzle
(for Light weight 16-,12-, 8-nozzle head)
■Dual conveyor
