NPM-W 2 EJM7DE-MB-02M-00 2-1-6 -17 Single tray feeder main unit Maintenance 2-1-6 P eriodic inspection points by unit 10 <Others> (option) Refuse box T win tray feeder main unit Refuse box Over- view
NPM-W2 EJM7DE-MB-02M-00
2-1-6-16
Overview
■Single conveyor
Support pin automatic change
Front and rear sides
PCB-support block
(for automatic
change)
■Nozzle changer for support
pin
■Support pin
(for automatic change)
■Support pin nozzle
Nozzle reflector
Nozzle flange upper
surface
(2D code area)
Nozzle taper surface
Nozzle inside
Nozzle tip
(Vacuum pad)
1100-nozzle
(for 3-nozzle head)
100-nozzle
(for Light weight 16-,12-, 8-nozzle head)
■Dual conveyor
NPM-W2 EJM7DE-MB-02M-00
2-1-6-17
Single tray feeder main unit
Maintenance
2-1-6
Periodic inspection points
by unit 10
<Others> (option)
Refuse box
Twin tray feeder main unit
Refuse box
Over-
view
NPM-W2 EJM7DE-MB-02M-00
2-1-6-18
Overview
Single tray feeder lifter
Ball screw
Linear guide
Twin tray feeder lifter
Tray feeder drawer
Ball screw
Tray feeder drawer
Linear guide
