NPM-W 2 EJM7DE-MB-02M-00 2-1-7 -3
NPM-W2 EJM7DE-MB-02M-00
2-1-7-2
Overview
Components or units required to replace within 10 years
Components or units required to replace within 5 years
See the Parts list and the Wiring diagram for details of components.
Number Name Quantity Kit number/Name
KXF0E381A00 GAS-SPRING 4
N610154523AA/
Whole cover: NPM-W2
N610163822AA
XY-axis wiring at F side:
NPM-W2
1
N610156475AA/
XY unit: NPM-W2
N610163823AA
XY-axis wiring at R side:
NPM-W2
1
Number Name Quantity Kit number/Name
N510037010AA POWER-SUPPLY 1
MTKA002491AA/
CPU BOX
N510069246AA
MOTOR-DRIVER
2
N610167687AA/
Main unit control : NPM-W2
N510069247AA 2
N510044504AA 2
N610067177AD/
Tray feeder box: NPM
N510063724AA POWER-SUPPLY 2
MTKA001180AA/
POWER UNIT
：
NPM-W2
N510057939AA MOTOR-DRIVER-PARTS 2
N610117722AA/
Main unit control: NPM-W2
N510033171AA POWER-SUPPLY 1
N610067177AD/
Tray feeder box: NPM
N510038308AA
POWER-SUPPLY
(Power Unit)
1
MTKA001180AA/
POWER UNIT: NPM-W2
POWER-SUPPLY
(Tray)
1
N610067177AD/
Tray feeder box: NPM
N510055083AA
TEMPERATURE
CONTROLLER
1
N610083275AA/
Dispensing head control
：
NPM
NPM-W2 EJM7DE-MB-02M-00
2-1-7-3
3 Tasks related to
maintenance
