NPM-W 2 EJM7DE-CT-01 M-00 S-14 6 P eriodic Inspection Ev er y-560- hour s -1 Greasing the PCB conveyor -2 Greasing the XY -axis linear guide -3 Greasing the nozzle holder -4 Cleaning the nozzle (option) and the nozzle ch…

NPM-W2 EJM7DE-CT-01M-00

-1

Cleaning the touchscreen

-2

Cleaning the nozzle holder

(3-nozzle head(option))

-3

Cleaning the PCB-support blocks

-3-1

Cleaning the PCB-support blocks

(Single conveyor specifications)

-3-2

Cleaning the PCB-support blocks

(Dual conveyor specifications)

-4

Cleaning the cover glass

(multi-recognition camera)

-5

Cleaning the feeder table

(feeder cart,13-slot feeder(option))

-6

Cleaning the table surface

(tray feeder drawer(option))

-7

Cleaning the calibration jig

(2D inspection head(option))

-8

Cleaning and checking the dummy

dispensing plate

(dispensing head(option))

-9

Checking the connector

(feeder cart,13-slot feeder(option))

-1

Before operation

-1-1

Inspecting the pressure gauge

-1-2

Checking the dummy dispensing tape

(dispensing head(option))

-2

After operation

-2-1

Cleaning the components-ejection box

-2-2

Cleaning the used-tape box

(feede

cart: and 13-slot feeder(option))

-2-3

Cleaning the refuse box

(tray feeder(option))

-2-4

Cleaning the wiping station (dispensing

head(option))

-2-5

Cleaning and checking the screw unit and the

nozzles (dispensing head(option))

-3

As needed

-3-1

Cleaning an inspecting the pallet

(fray feeder pallet(option))

Periodic

inspection

Every-24-

hours

Periodic

inspection

Every-140-

hours

S-13

NPM-W2 EJM7DE-CT-01M-00

S-14

Periodic

Inspection

Every-560-

hours

-1

Greasing the PCB conveyor

-2

Greasing the XY-axis linear guide

-3

Greasing the nozzle holder

-4

Cleaning the nozzle (option) and the

nozzle changer

(option)

-5

Inspecting PCB/extension

conveyor

(option)

-6

Cleaning the large reflector

(3-nozzle head(option))

-7

Cleaning the vacuum pump filter

-8

Inspecting the safety switches

-9

Cleaning the PCB detection

sensors

-10

Inspecting the vacuum air path

(placement head(option))

-11

Inspecting the θ-axis belt

(placement head(option))

-12

Cleaning the components-ejection

conveyor

(option)

-13

Greasing to the tray feeder (option)

-14

Cleaning the slot

(tray feeder magazine(option))

-15

Cleaning the safety cover

-16

Inspecting the air drain

(regulator unit)

-17

Greasing the cutting unit

-18

Cleaning the light-emitting and

light-receiving sections

(height sensor(option))

-19

Greasing the dispensing head

(option)

-20

Greasing the dummy dispensing

unit

(dispensing head(option))

-21

Cleaning the nozzle (option) and

nozzle changer

(option) for support

pins

-22

Cleaning the XY-axis cable bearer

NPM-W2 EJM7DE-CT-01M-00

S-15

Periodic

inspection

Every-3000-

hours

-1

Inspecting the backlight

(touchscreen)

-2

Applying grease to the hinge

(touchscreen)

-3

Inspecting the 1006 nozzle (option)

Periodic

inspection

Every- 6000-

hours

Periodic

inspection

Every-

18000-hours

-1

Inspecting the nozzle holder (option)

-2

Inspecting the cable bearer (XY unit)

-3

Replacing the spring

(dispensing head(option))

-4

Replacing the heater/thermocouple

(dispensing head(option))

-1

Cleaning the filter (main controller)

-2

Cleaning the filter of the FA computer

(inspection box(option))

-3

Replacing the O-ring

(dispensing head(option))

-4

Replacing the collar

(dispensing head(option))

-5

Adjusting white balance

(2D inspection head(option))

-1

Cleaning the nozzle holder

(Light weight 16-/12-/8-nozzle head(option))

Periodic

inspection

Every-1000-

hours
