NPM-W 2 EJM7DE-CT-01 M-00 S-15 8 P eriodic inspection Ev er y-3000- hour s 9 -1 Inspecting the backlight (touchscreen) -2 Applying grease to the hinge (touchscreen) -3 Inspecting the 1006 nozzle (option) P eriodic inspec…
NPM-W2 EJM7DE-CT-01M-00
S-14
6
Periodic
Inspection
Every-560-
hours
-1
Greasing the PCB conveyor
-2
Greasing the XY-axis linear guide
-3
Greasing the nozzle holder
-4
Cleaning the nozzle (option) and the
nozzle changer
(option)
-5
Inspecting PCB/extension
conveyor
(option)
-6
Cleaning the large reflector
(3-nozzle head(option))
-7
Cleaning the vacuum pump filter
-8
Inspecting the safety switches
-9
Cleaning the PCB detection
sensors
-10
Inspecting the vacuum air path
(placement head(option))
-11
Inspecting the θ-axis belt
(placement head(option))
-12
Cleaning the components-ejection
conveyor
(option)
-13
Greasing to the tray feeder (option)
-14
Cleaning the slot
(tray feeder magazine(option))
-15
Cleaning the safety cover
-16
Inspecting the air drain
(regulator unit)
-17
Greasing the cutting unit
-18
Cleaning the light-emitting and
light-receiving sections
(height sensor(option))
-19
Greasing the dispensing head
(option)
-20
Greasing the dummy dispensing
unit
(dispensing head(option))
-21
Cleaning the nozzle (option) and
nozzle changer
(option) for support
pins
-22
Cleaning the XY-axis cable bearer
NPM-W2 EJM7DE-CT-01M-00
S-15
8
Periodic
inspection
Every-3000-
hours
9
-1
Inspecting the backlight
(touchscreen)
-2
Applying grease to the hinge
(touchscreen)
-3
Inspecting the 1006 nozzle (option)
Periodic
inspection
Every- 6000-
hours
10
Periodic
inspection
Every-
18000-hours
-1
Inspecting the nozzle holder (option)
-2
Inspecting the cable bearer (XY unit)
-3
Replacing the spring
(dispensing head(option))
-4
Replacing the heater/thermocouple
(dispensing head(option))
-1
Cleaning the filter (main controller)
-2
Cleaning the filter of the FA computer
(inspection box(option))
-3
Replacing the O-ring
(dispensing head(option))
-4
Replacing the collar
(dispensing head(option))
-5
Adjusting white balance
(2D inspection head(option))
-1
Cleaning the nozzle holder
(Light weight 16-/12-/8-nozzle head(option))
7
Periodic
inspection
Every-1000-
hours
NPM-W2 EJM7DE-CT-01M-00
S-16
12
Consumable
parts
replacement
-1
Replacing the transfer belt of the
PCB transfer conveyor
-2
Replacing the PCB transfer belt of
the extension conveyor
(Option)
-3
Replacing the batteries
-4
Replacing the dummy dispensing
tape
(dispensing head(option))
-5
Replacing the cushion (wiping
station)
(dispensing head(option))
-6
Replacing the air filter element of
the placement head
(Light weight 16-
nozzle)
-7
Replacing the air filter element of
the placement head
(12-nozzle)
-8
Replacing the air filter element of
the placement head
(8-nozzle)
-9
Replacing the air filter element of
the placement head
(3-nozzle)
Replacement
11
-1
Head and nozzle changer
replacement
-2
A
ttachment without head
-3
Mode switch
-3-1
Switching to the single lane mode
-3-2
Confirming switch
