N7201A617E00_0317 - 第152页
NPM-W 2 EJM7DE-MB-04M-00 Clean the (whole) upper surface of the pallet As needed Maintenance 4-3-1 Tool used: Lint free cloth Time required: 2 minutes (per location) V isually check the drawer block V isually check the p…
NPM-W2 EJM7DE-MB-04M-00
4-2-5-8
20
● Check that the lock plate comes to the lock position.
21
Lock plate
Connect the air
plug
22
Take out the
cloth covered
with the multi-
recognition
camera and the
nozzle changer
23
Rotate the lock plate in the counterclockwise direction, and
lock the syringe
SERVO
ON
24
Every
24
hours
PeriodicPeriodic
inspection
NPM-W2 EJM7DE-MB-04M-00
Clean the (whole)
upper surface of
the pallet
As
needed
Maintenance
4-3-1
Tool used: Lint free cloth Time required: 2 minutes (per location)
Visually check
the drawer
block
Visually check
the pallet for
warps
Drawer block
Pallet upper
surface
●If you find any cracks or
chips, avoid using the
pallet.
●If it is warped, fix it.
Cleaning and inspecting
the pallet
(tray feeder pallet(option))
2
1
3
4-3-1
Describes cleaning and inspecting the pallet.
5 Periodic inspection
Every-140-hours
