NPM-W2 EJM7DE-MB-05M-00
Every
140
hours
PeriodicPeriodicPeriodic
inspection
5-3-2-2
■For PCB-support block (for automatic change) (option)
If the PCB block
is switched position with ,
E
F
you cannot change to the arrangement of the single
lane mode.
●Arrangement on single mode●Arrangement on dual mode
Front
Rear side
E
F
E
F
E E
F F
Front
Rear side
F
E
基板下受け
ブロック
Product No.
Outline drawing of PCB support block
Remarks
Back surface Front surface
N610145010AB Standard
N610145011AB Option
NPM-W2 EJM7DE-MB-05M-00
5-3-2-3
ENABLING
1
ENABLING
2
3
Confirm the
message
Detach the
feeder cart
(→P.3-2)
Front side
(X-axes in the front and
rear move to the retraction
position)
Cleaning
the PCB-
support
blocks
Cleaning the PCB-support
blocks
(dual conveyor specifications) 2
Maintenance
5-3-2
9
Clean the PCB holder and the PCB-support
block
●Use a lint free cloth or brush.
●Clean the top surface of the
PCB support block (for
automatic change) with a lint
free cloth dampened with
alcohol.
●Be careful not to scratch
coating material on the
surface of the PCB support
block (for automatic change)
by sharps.
10
Attach the PCB-
support block as
it is no tilt
●PCB-support block
：4 blocks
PCB-support block
Guide pin
12
11
Return the feeder
table cover back
Remove the lint
free cloth
●If it tilts, it interferes with
the rail.
NPM-W2 EJM7DE-MB-05M-00
5-3-2-4
Every
140
hours
PeriodicPeriodicPeriodic
inspection
To
16
Fold the feeder
table cover to
the back
Cover the multi-
recognition
camera with a
lint free cloth
OFF
SERVO
4
6
5
7
8
PCB-support block
Remove the PCB-support block
●PCB-support block：4 blocks
●Be careful not to drop an
object on the multi-recognition
camera or bump the multi-
recognition camera.
●If there are support pins on
the PCB-support block, be
careful not to fall them.
SERVO
ON
14
15
13
Attach the feeder
cart (→P.3-2)
Front side
●Neither lean against the
feeder table cover nor place
anything on it.
